BROAD SCAN (HD/SDI)
3-2. USING THE FRAME STORE
This function allows memorizing a frame (an image) in order to display it at any time during the show.
• HOW TO STORE A FRAME:
 Connect the source of the frame to be stored to the input of the BROAD SCAN. Perform and auto-setting to display
it onto the output.
 Select the Record frame mode (LOGOS/FRAMERecord Frame): the device displays a white rectangle
corresponding to the frame selection area onto the output. Then adjust the position and size of the frame selection
area with the menu functions (LOGOS/FRAMERecord FramePosition – Size).
 Store the frame (LOGOS/FRAMERecord FrameStore). The memorization starts and will take about 30
seconds.
• HOW TO DISPLAY THE FRAME:
The FRAME can be displayed either by the front panel FRAME push button or either by the menu
(LOGOS/FRAMEFrame ON). Select OFF to switch OFF the frame.
NOTE: The frame can be automatically displayed when the sync of the selected input is not anymore detected. Select
(CONTROLAuto frame ON) to activate this function.
PAGE 18
