QUICK START GUIDE

What’s in the box

Quick install and setup

Thank you for choosing

Analog Way

and the

Smart Quad

. By following these simple steps, you should be able to setup

and use your powerful Hi-Resolution Mixer Switcher within minutes. Discover the

Smart Quad

extensive capabilities

and intuitive interface while configuring your first show, and unleash your creativity for a new experience in show and

event management by

Analog Way

Smart Quad - Ref. SQD200

1 x

Smart Quad

(SQD200)

1 x AC Power cable

2 x DVI-I male to HD15 female and DVI-D female breakout cable

1 x HD15 to 5 BNC cable

1 x Ethernet cross cable (for device update)

1 x DB9 to 4 BNC cable + mini-Din 4

1 x Set of 3 audio 10-pin screw terminals

4 x M4x12mm screws

1 x RCS - Remote Control Software (PC only) *

1 x Quick Start guide (PDF version) *

1 x User Manual (PDF version) *

* Download on our website:

www.analogway.com

Key points:

• Red led: Source is on Main
• Blinking button: Source selected for modification
• dSK function is available
• BlACK button allows to remove layer (Clear function)

Getting started:

1. Observe all safety precautions. Rackmount chassis

(please refer to user’s manual) or install in «table

top» configuration.

2. Connect all inputs (please refer to user’s manual:

Input specification).

3. Power on.
4. Perform factory reset:

• Press the exIt/Menu button, from the Home

• Select [Control] > navigate in the Menu by

rotating the corresponding knob

• Press the enteR button to enter the control

sub-menu

• Select [default Values] and press enteR

button. this operation should take approximately

30 seconds.

IMPORTANT: simply selecting a menu item will not

set it to that value. Be sure to press the

ENTER button

when parametering the menu items.

WARNING !

If required, front handles of the device can be dismantled,

but with caution.

The original screws removed must not be reintroduced to

their location without handles in place.

Substantial damages can occur, including risk of elec-

tric shock from the mains voltage.

Only

M4x12mm screws can be used.

(They are supplied with the unit)
