Analog Way Smart MatriX LE User Manual

Page 4

Going further with the SMX100

For complete details and operations procedures, please refer to the

Smart MatriX LE

User’s Manual and our website for

further information:

www.analogway.com

Version: 4.0 - 20/12/2011

Code: 140125

Warranty

This

Analog Way

product has a 3 year warranty on parts and labor, back to factory. This warranty does not include faults

resulting from user negligence, special modifications, electrical surges, mishandling (drop/crush), and/or any other damage

caused by misuse.

How to do an AutoTake?

Sync.loss function

How to disable the HDCP encryption?

How to use the Auto-Lock Function?

[AUTO-LOCK]

allows to select an input only if a signal is connected.

HOME MENU (extract)

INPUT

CONTROL

MAIN OUT

PREVIEW OUT

CONTROL

DVI1 or DVI2

Auto-Lock

HDCP Detection

AutoTake

Sync.loss

HDCP enable

Disabled

Automatic

The HDCP Encryption can be disabled on DVI inputs #1 to #2 or/and Main Output / Preview Output. This can be useful

when you have a computer which is detecting the HDCP compliance of your switcher and protecting the content by

encrypting the signal from this computer. This feature will disable the HDCP compliance on this specific DVI input only.
If you want to use HDCP content from your sources, be sure to use only HDCP compliant screens or projector. If it’s not

the case, the output image could be disabled.
Screen will go to black without displaying the HDCP input image, or partially layer out on HDCP content.

The output status can provide you all information about the output in real time. This feature is particularly useful when

HDCP is used with long cable to be sure the communication is well handled.

The Autotake function performs a TAKE automatically each time an input is selected.

This Sync.loss funtion allows you to choose a backup source in the case where one of your input will be disconnected.

The designed source will replace automatically the unplugged source.



Enabled or disabled

Select input

Enabled or disabled
