5
1
1 . Power on/off and volume control knob
Press and hold for 3 seconds to turn the unit off. Press again to turn the unit
on. Increase the volume by rotating the knob clockwise. Decrease the volume
by rotating the knob counter-clockwise.
2 . AV IN Jack
Jack (3.5mm) which provides an audio or video input jack.
3 . Microphone
The microphone is located on the left side of the unit. For best reception,
speak loudly and clearly.
4 . REMOTE CONTROL SIGNAL RECEIVER
Receives the IR signal from the remote control.
5 . Disc Slot
Accepts DVD/CD/MP3 discs.
6 . SD Card slot
Insert SD card for playback of audio/video files.
7 . Disc LED Indicator
LED which lights red when a disc is inserted in the radio and lights white
when the disc slot is empty.
8 . Button
Press this button to eject a DVD/CD/MP3 disc. Disc play is stopped, the disc
is ejected and the unit will change to radio operation. If the disc is not
removed from the unit and the button is pressed again, the disc will be
re-loaded. If the disc is not removed from the disc slot within 10 seconds
of being ejected, it will be automatically re-loaded to prevent it from being
accidentally damaged.
2 3 4 5 6 7 8 9
10
11
12
13
14
18
17
16
15
Controls and Indicators
