iC-Net Tips – RF Design and Installation
Typical Commands
Command
Description
All Controllers
Power Off
P0
P (Zero)
Power On
P1
P (One)
Tune Analog
TC
2-127
HD Tuning
TH
Example: TH then 15,1 tunes channel 15-1
Volume
VL
Sets TV volume level
0 = Mute
1 – 63 = Minimum level (1) to maximum volume (63)
Tuning
ICC1-232, ICC1-IR
Tuning Style
H1
1 = 5-digit CableCard style tuning (1-9999)
2 = Virtual HD Major-Minor tuning (tunes to virtual channel ID in display)
3 = Physical HD Major-Minor tuning (physical channel, minor digital)
RS-232
ICC1-232, ICC2-ATSC, ICC2-VDC
RS-232 Control
T0
Selects control make and model for RS-232 control. Check Manual or
product Install page for codes
Tuning Format
ATSC,VDC,IRC
S0
0=CATV
1=Off-Air
2=IRC
3=HRC
4=Auto
Direct
UX
Sends an RS-232 command directly to a display or projector through the
controller’s RS-232 port.
Example:
UX 'mc 00 39',13 [Device #] sends a toggling Captions On/Off command to an
LG display.
ASCII character strings can be denoted by enclosing in single quotes (or double
quotes if you actually needed the single quote character in the string). Hex bytes
are denoted with a $ symbol. Decimal characters are without quotes.
Scan
ICC2-ATSC
Scan Mode
D0
Sets scan mode for digital and analog channels from the T^ or front panel scan
command.
0= Scans for analog and digital channels scan (default)
1= Scans for digital only, deletes analog channels
2= Scans for digital only, keeps analog channels
3= Scans for analog only, deletes digital channels
4= Scans for analog only, keeps digital channels
Channel Scan
T^
Initiates channel scan
IR
ICC1-IR, ICC2-IRC
IR Code
T1= Sets IR control code.
Check Manua
Install page for codes
