Contemporary Research 6 iC-Net Tips – RF Design and Installation
IR Control Test
The ICC1-IR controller has a library of codes inside. In most installs, CR has already pre-set
the control code on the unit. This can be changed with the switches, or through IC Send or
Display Express software. As a rule, the dealer should pre-set this at the shop (or with CR).
As the switches are also used to set the controller’s address, this shouldn’t be done in the
field with your level one Hang and Bang installers.
However, they can test operation very simply.
Turn S2 Switch 6 ON
Flip S2 Switch 1 On – this will send an IR Power On command to the display, then
turn the switch off
Flip S2 Switch 1 On – this will send an IR Power Off command to the display, then
turn the switch off
Turn S2 Switch 6 OFF
RS-232 Control
This step isn’t required, as we always install just one code series into the ICC1-232
controller at CR. We find that this dramatically reduces installer error. Most integrators test
one of the controllers at the shop to cross-check operation before installation.
S2 OFF ON
1 Power On
2 Power Off
3
4
5
6 Test Mode On
7
8
