Installation Instructions KWT-110
3
DIMENSIONS
9.47
240
36.15
918
FLEXIBLE/REMOVEABLE
CABLE MANAGEMENT
COVERS
.88
22
.60 DEPTH FROM WALL
TO ACCESSORY
MOUNTING SURFACE
15
CABLE
MANAGEMENT
CHANNELS
VERTICAL INSTALLATION
KEYBOARD TRAY
MAX WEIGHT: 10LBS.
MONITOR MOUNT
MAX WEIGHT: 25LBS.
4.50
114
.50
13
6.91
176
.25 TYP.
HOLE SIZE
6
10.00
254
16.00
406
20.00
508
32.00
813
HORIZONTAL INSTALLATION
CPU WALL MOUNT
MAX WEIGHT: 40LBS.
