2.5.4

Hardware Monitor

The items in this sub-menu displays the hardware monitor values
automatically detected by the BIOS. It also allows you to change CPU Q-Fan
feature-related parameters. Select an item then press to display
the configuration options.

Q-Fan Controller [Disabled]

Allows you to enable or disable the Q-Fan controller.
Configuration options: [Disabled] [Enabled]

Vcore Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage

The onboard hardware monitor automatically detects the voltage output
through the onboard voltage regulators.
Configuration options: [xxx] [Ignored]

CPU Temperature, M/B Temperature

The onboard hardware monitor automatically detects and displays the
motherboard and CPU temperatures. These items are not user-configurable.

CPU Fan Speed [xxxxRPM]

CPU Fan Speed [xxxxRPM]
Chassis Fan1/Fan2 Speed [xxxxRPM]

Chassis Fan1/Fan2 Speed [xxxxRPM]

Chassis Fan1/Fan2 Speed [xxxxRPM]
Power Fan Speed [xxxxRPM]

Power Fan Speed [xxxxRPM]

The onboard hardware monitor automatically detects and displays the CPU,
Chassis, and chip fan speeds in rotations per minute (RPM). If any of the
fans is not connected to the motherboard, the field shows 0. These items
are not user-configurable.

CPU Fan Speed warning [800 RPM]

Sets the CPU fan speed warning feature.
Configuration options: [Disabled] [800RPM] [1200RPM] [1600RPM]

Select Menu

Item Specific Help

Press [Enter] to
enable or disable

Hardware Monitor

Q-Fan Controller

[

Disabled

]

Vcore Voltage

[1.56V]

3.3V Voltage

[3.18V]

5V Voltage

[5.05V]

12V Voltage

[11.58V]

CPU Temperature

48ºC

M/B Temperature

41ºC

CPU Fan Speed

3068 RPM

Chassis Fan1 Speed

0 RPM

Chassis Fan2 Speed

0 RPM

Power Fan Speed

0 RPM

CPU Fan Speed warning

[800 RPM]

Phoenix-Award BIOS CMOS Setup Utility
