A S U S M 2 N P V - V M A S U S M 2 N P V - V M A S U S M 2 N P V - V M A S U S M 2 N P V - V M A S U S M 2 N P V - V M 2 - 2 9 2 - 2 9 2 - 2 9 2 - 2 9 2 - 2 9
Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4]
[2E8/IRQ3] [Auto]
Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4]
[2E8/IRQ3] [Auto]
Parallel Port Address [378/IRQ7] Parallel Port Address [378/IRQ7] Parallel Port Address [378/IRQ7] Parallel Port Address [378/IRQ7] Parallel Port Address [378/IRQ7]
Allows you to select the Parallel Port address.
Configuration options: [Disabled] [378/IRQ7] [278/IRQ5] [3BC/IRQ7]
Parallel Port Mode [EPP] Parallel Port Mode [EPP] Parallel Port Mode [EPP] Parallel Port Mode [EPP] Parallel Port Mode [EPP]
Allows you to select the Parallel Port mode.
Configuration options: [Normal] [EPP] [ECP] [Bi-Directional]
The “ECP Mode Use DMA” item becomes user-configurable when the “
Parallel Port Mode” item is set to [ECP] or [Bi-Directional]
ECP Mode Use DMA [3]
Allows selection of ECP Mode. Configuration options: [1] [3]
Game Port Address [201] Game Port Address [201] Game Port Address [201] Game Port Address [201] Game Port Address [201]
Allows you to select the Game Port address or to disable the port.
Configuration options: [Disabled] [201] [209]
Midi Port Address [201] Midi Port Address [201] Midi Port Address [201] Midi Port Address [201] Midi Port Address [201]
Allows you to select the Midi Port address or to disable the port.
Configuration options: [Disabled] [330] [300]
Midi Port IRQ [10] Midi Port IRQ [10] Midi Port IRQ [10] Midi Port IRQ [10] Midi Port IRQ [10]
Allows you to select the Midi Port IRQ.
Configuration options: [5] [10]
