Maximum payload size [4096, Ide function setup – Asus M2NPV-VM User Manual

Page 70

2 - 2 6

C h a p t e r 2 : B I O S s e t u p

IRQ-xx assigned to

When set to [PCI Device], the specific IRQ is free for use of PCI/PnP
devices. When set to [Reserved], the IRQ is reserved for legacy ISA
devices. Configuration options: [PCI Device] [Reserved]

Maximum Payload Size [4096]

Sets maximum TLP payload size for the PCI Express devices. The unit is
byte. Configuration options: [128] [256] [512] [1024] [2048] [4096]

Select Menu

Item Specific Help

Disable/Enable OnChip
IDE Channel0

Phoenix-Award BIOS CMOS Setup Utility

Advanced

IDE Function Setup

This sub-menu contains IDE function-related items. Select an item then
press to edit.

IDE Function Setup

OnChip IDE Channel0

[

Enabled

]

OnChip IDE Channel1

[Enabled]

IDE DMA transfer access

[Enabled]

SATA Port 1, 2

[Enabled]

SATA DMA transfer

[Enabled]

SATA Port 3, 4

[Enabled]

SATA2 DMA transfer

[Enabled]

IDE Prefetch Mode

[Enabled]

F1:Help

↑↓

↑↓ : Select Item

-/+: Change Value

F5: Setup Defaults

ESC: Exit

→←

→←: Select Menu

Enter: Select Sub-menu F10: Save and Exit

Select Menu

Item Specific Help

Press [Enter] to set

Onboard Device Configuration

IDE Function Setup

NVRAID Configuration
USB Configuration
Onboard NV LAN

[Enabled]

Onboard LAN Boot ROM

[Disabled]

Onboard IEEE 1394

[Enabled]

HD Audio

[Enabled]

Serial Port1 Address

[3F8/IRQ4]

Serial Port2 Address

[2F8/IRQ3]

Parallel Port Address

[378/IRQ7]

Parallel Port Mode

[Normal]

x ECP Mode Use DMA

Game Port Address

[201]

Midi Port Address

[330]

Midi Port IRQ

[10]

Phoenix-Award BIOS CMOS Setup Utility

Advanced

2.4.6

Onboard Devices Configuration
