Installation Instructions Model: K-Series
4
SPECIFICATIONS
Table 1: Mounts
MODEL NO. OF
DISPLAYS
SUPPORTING
STRUCTURE
NO. OF
MOUNTING
ARMS
ADJUSTABLE
HEIGHT
MAX.
EXTENSION
(INCHES)
MIN.
CLOSED
DEPTH
(INCHES)
MAX.
SUPPORT
WEIGHT
(LBS.)
PER MONITOR
KWP-110 Single Wall None No None 2.9 40
KWV-110 Single Wall Single Yes 13 2.2 25
KWS-110 Single Wall Single No 9.5 2.2 40
KWG-110 Single Wall Dual Yes 19.5 2.2 25
KWD-110 Single Wall Dual No 16 2.2 40
KWB-110 Single Wall Triple Yes 26 2.2 25
KCV-110 Single Desk Single Yes 13.5 2.2 25
KCS-110 Single Desk Single No 10 2.2 40
KCG-110 Single Desk Dual Yes 20 2.2 25
KCD-110 Single Desk Dual No 16.5 2.2 40
KCB-110 Single Desk Triple Yes 26.5 2.2 25
KPP-110 Single Pole None No None 2.2 40
KPS-110 Single Pole Single No 9.5 2.2 40
KPD-110 Single Pole Dual No 16 2.2 40
KPG-110 Single Pole Single Yes 16.5 2.2 25
KPV-110 Single Pole Single Yes 13.3 2.2 25
KWD-130 Single Wall Single Yes 18.6 5.1 25
KWS-220 Dual Wall Single No 13.5 6.4 17
KWD-220 Dual Wall Dual No 20 6.4 17
KCS-220 Dual Desk Single No 14 6.4 40
KCD-220 Dual Desk Dual No 20.5 6.4 17
KCY-210 Dual Desk Multi-Dual Yes (one arm) 20 2.2 20
KCY-220 Dual Desk Multi-Dual Yes (two arms) 20 2.2 20
KWD-230 Dual Wall Single No 18.6 5.9 40
KWS-320 Triple Wall Single No 13.5 6.4 10
KWD-320 Triple Wall Dual No 20 6.4 10
KCS-320 Triple Desk Single No 14 6.4 10
KCD-320 Triple Desk Dual No 20.5 6.4 10
KGL-110 Tray Desk Single Yes 29.5 14 18
KGL-220 Single/Tray Desk Dual Yes 29.5 14 40 total
Table 2: Accessories
MODEL NO. OF
MONITORS
SUPPORTING
STRUCTURE
NO. OF
MOUNTING
ARMS
ADJUSTABLE
HEIGHT
MAX.
EXTENSION
(INCHES)
MIN.
CLOSED
DEPTH
(INCHES)
MAX.
SUPPORT
WEIGHT
(LBS.)
PER MONITOR
KMA-220 Dual N/A N/A N/A N/A N/A 17
KMA-320 Triple N/A N/A N/A N/A N/A 10
KMA-325 Triple N/A N/A N/A N/A N/A 10
KSA-1015 N/A Wall Single No 16 6.4 75
KSA-1016 N/A Wall Dual No 24.5 6.4 75 total
