Setup function
4 - 1
Chapter 4
Setup function
All of the parameters required for correct operation of the N100 instrument can be set in
the setup screen. You can scroll up and down the list of parameters that can be set using
the and arrows.
The parameter selected will be displayed in white on a black background (in negative).
To edit the value press the key, insert the desired value when requested to do so,
then confirm with the
key.
To quit the edit function without changing the previous value press .
Sensor sensitivity
The N100 instrument can be used with various types and models of sensors, and therefore
for correct measurement you must set the exact degree of sensitivity (= number of volts
per unit) of that effectively connected. Press the
key to vary the sensitivity of
the sensor selected, varying one figure at a time.
The and arrows increase or decrease the figure selected (displayed in
negative) by one unit.
By pressing and , the figure on the left or on the right can be selected respectively.
For both possible types:
-
accelerometer
ACC
-
velocimeter
VEL
-
displacement
DIS
