5.3.2 - MANUAL PRESETTING
If necessary, the dimensions can be inserted or edited in manual mode as follows:
- press + .
- press to select the dimension to be preset (red).
- press / to preset the required value.
- press to change unit of measurement.
- press to preset the dimensions for the ALU-S correction mode
Definition of dimensions for correction using spring weights:
d = DIAMETER: Preset the nominal diameter stamped on the rim.
b = WIDTH: Preset the nominal width indicated on the rim.
a = DISTANCE: Preset the distance of the inside of the wheel from the machine, after measuring
it with relative gauge as described in fig. 8.
In the event of correction type other than standard (spring weight), follow the instructions on the screen
for correct detection of dimensions.
