I 0322 - 12
I 0322 - 13
POS A
POS B
8
9
GB GB
5.3 - PRESETTING OF WHEEL DIMENSIONS
5.3.1 - AUTOMATIC PRESETTING (see also CORRECTION MODE )
5.3.1.1 - STANDARD WHEELS
The screen appears upon removing the distance + diameter gauge.
The “dimension acquired” message is indicated by the correction weight symbol, which changes from
blue to red.
- INNER SIDE WEIGHT: Using the special grip, move the end of the gauge against the rim in position:
a)
Sprung weight : in one of the positions A/B indicated in figure 8.
INDICATOR
L.T. function enabled
(see Buttons
Enabled)
INDICATOR: Width
Sonar function
enabled
b) Adhesive weight: in the position indicated below
- Hold the gauge in position for at least 2 seconds.
If the acoustic signal is enabled (see
ACOUSTIC SIGNAL ), the acquisition of the dimensions is accompanied
by a “beep”.
Position of
adhesive
weight
