Rlp-200 parts list, 8rlp-200 leg press / hack squat – Tuff Stuff RLP-200 Leg Press/Hack Squat User Manual
Page 8
REV0
ITEM
DESCRIPTION
REV
PART NO.
QTY
ITEM
DESCRIPTION
PART NO.
QTY
1
ADJUSTABLE CHROME TUBE
0
UP3938
1
37
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 1
BNH0842
2
2
ADJUSTABLE FOOT PLATE
0
UP3939
1
38
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 2 3/4
BNH2065
2
3
ADJUSTMENT TUBE HOUSING
0
UP3940
1
39
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 3
BNH0331
4
4
BASE FRAME
0
UP3941
1
40
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 5 1/2
BNH2066
1
5
CARRIAGE
0
UP3942
1
41
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 5 5/16
BNH2048
2
6
CARRIAGE HANDLE
0
UP3943
2
42
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 6 1/4
BNH2067
2
7
HACK SQUAT FOOT PLATE
0
UP3944
1
43
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 1/4
BNH2038
14
8
HANDLE STOPPER LEFT SIDE
0
UP2229
1
44
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 1/2
BNH2044
2
9
HANDLE STOPPER RIGHT SIDE
0
UP2228
1
45
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/4
BNH2045
6
10
HEAD SUPPORT PAD
0
UP3945
1
46
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3
BNH2046
4
11
LEFT SIDE FRAME RAIL
0
UP3946
1
47
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 5
BNH2051
2
12
LINEAR SHAFT 1 3/16 X 59 1/2
0
UP3947
2
48
HEX HEAD CAP SCREW GR-5 Z/P 5/16-18 X 3/4
BNH2049
1
13
LOWER BACK PAD
0
UP3948
1
49
HEX HEAD CAP SCREW GR-5 Z/P 5/16-18 X 5 1/2
BNH2069
2
14
PAD BRACKET
0
UP0087
4
50
HEX HEAD CAP SCREW GR-5 Z/P 5/16-18 X 5/8
BNH2068
16
15
REAR FRAME
0
UP3949
1
51
HEX KEY 3/32"
BNH0373
1
16
RIGHT SIDE FRAME RAIL
0
UP3950
1
52
HEX KEY 7/32"
BNH0575
1
17
SEAT PAD
0
UP3951
1
53
LITHIUM GREASE SMALL CONTAINER
BNH0705
1
18
SHOULDER PAD LT SIDE
0
UP3952
1
54
METAL HINGE
BNH0046
2
19
SHOULDER PAD RT SIDE
0
UP3953
1
55
NYLON INSERT JAM LOCK NUT Z/P 1/2-13
BNH2027
11
20
SPACER 7/8
0
UP3954
2
56
NYLON INSERT JAM LOCK NUT Z/P 3/8-16
BNH2026
14
21
UPPER BACK PAD
0
UP3955
1
57
PLASTIC HORIZONTAL ELLIPTICAL SHOE
BNH1847
2
22
WEIGHT HOLDER
0
UP3956
1
58
PLASTIC INSERT CAP 2 X 3 _ 11-14 GA
BNH0052
2
23
WEIGHT HOLDER SUPPORT
0
UP3957
1
59
PLASTIC INSERT CAP 2" SQ
BNH0012
6
24
ALUMINUM CAP 1.020" RD
BNH0537
4
60
PLASTIC INSERT CAP ELLIPTICAL 2 X 4
BNH1794
2
25
ALUMINUM PILLOW BLOCK BEARING
BNH2072
4
61
PLASTIC INSERT CAP FOR 1 13/64" HOLE DIA
BNH1317
2
26
BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8
BNH0528
4
62
PLASTIC INSERT ELLIPTICAL GUIDE (2X4)
BNH1760
1
27
CHROME CAP 1 7/8" RD.
BNH1016
2
63
PULL PIN 1/2 X 3 1/2 (YELLOW)
BNH0603
2
28
DECAL-CAUTION 1 3/4 X 5 1/2
BNH0126
1
64
RUBBER DONUT 1 X 2 1/2
BNH0062
2
29
DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2
BNH0142
2
65
RUBBER GRIP 1 ID X .125 X 5 1/2
BNH0958
2
30
DECAL-FOR BEST PERFORMANCE 1-1/4 X 1-1/2
BNH0143
3
66
RUBBER GRIP 1 ID X .125 X 8
BNH0966
2
31
DECAL-WARNING KEEP HANDS AND FINGERS..
BNH0620
2
67
RUBBER WASHER 1 7/8 ID X 3 OD X 9/16 TK
BNH1311
2
32
FLAT HEAD SOCKET CAP SCREW 3/8-16 X 1 1/4
BNH0667
2
68
SOCKET SET SCREW ALLOY 10-32 X 1/8
BNH0473
10
33
FLAT PHILLIPS SCREW ZINC # 2 X 1/2
BNH1480
2
69
SPACER 1/2 IDX 3/4 OD X 1 3/4 L
BNH2073
2
34
FLAT WASHER SAE Z/P 1/2"
BNH2031
18
70
SPLIT LOCK WASHER Z/P 5/16"
BNH2070
18
35
FLAT WASHER SAE Z/P 3/8"
BNH2030
42
71
TUFFSTUFF LOGO ALUMINUM SMALL
BNH1323
1
36
FLAT WASHER USS Z/P 5/16"
BNH2071
18
72
URETHANE BUMPER 1 3/4"
BNH0229
2
RLP-200
Parts List
COLOR CHART
BOLD FONT = SUB-ASSEMBLY PARTS
BLACK= HARDWARE
8
RLP-200 Leg Press / Hack Squat
