Schreiber Chillers 2203AC - 3-Stage Chiller User Manual

Page 16

Text mode
Original mode

Models:

Voltage:

Options:

230-460

3-Stages System Schematic

Schreiber Engineering Corp.

12111 Park St. Cerritos, CA 90701

(562)-926-3855

(562)-926-0969 Fax

Phase: 3

Type: Air/Water Cooled Chiller

Notes:

All motors have internal overload protection unless otherwise shown
On all connections: L1 - Blue L2 - Black L3- Red

Marks:

PUMP #1

Check valve 1

DISCHARGE

MANIFOLD

RETURN

MANIFOLD

HXC #1

HXC#2

HXC#3

EVAPORATOR #2

AND ISOLATION VALVE

EVAPORATOR #1

AND ISOLATION VALVE

AUTOMATIC

PRESS. RELIEF VALVE

40-PSI SET

BACKFLOW

PREVENTOR

STRAINER

DRAIN ½" FPT

SIGHT

GLASS

FILL/OVERFLOW

1" Npt

PUMP #2

Check valve 2

EVAPORATOR #3

AND ISOLATION VALVE

FLOW

SWITCH

HXC#4

HXC#5

Field Install

press. gauge

Field Install

Press. Gauge

Field install

flow meter

CHILLER INTERNAL

CHILLER EXTERNAL - FIELD INSTALLATION
