Title, Rev. descriptions date by – Schreiber Chillers 2203AC - 3-Stage Chiller User Manual
Page 13
Schreiber
Engineering
12111 EAST PARK STREET
CERRITOS, CA 90703
TITLE
MATERIAL
FINISH
SCALE:
DRAWING NO.
DRAWN BY:
DATE:
REV
DO NOT SCALE DRAWING
16 GA (.060 IN)
C-ROLLED
A
STEVEN Q. LY
SHT1 SHT2
B B
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCE ARE:
FRACTION DECIMALS ANGLES
+ .XX +.03
+.5
.XXX + .015
SHT OF
SIZE
B
REV. DESCRIPTIONS DATE BY
A DOVER INDUSTRIES COMPANY
SYSTEM CABINET DRAWING
NEVADA IMAGING CTR
3-750-001
09.14.04
53.500
100.375
78
.375
