Schreiber Chillers 15MEDAC_GEN2 - Manual (Page 25)

Schreiber
Engineering
12111 EAST PARK STREET
CERRITOS, CA 90703
TITLE
MATERIAL
FINISH
SCALE:
DRAWING NO.
DRAWN BY: DATE:
REV
DO NOT SCALE DRAWING
A
SHT1 SHT2
B B
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCE ARE:
FRACTION DECIMALS ANGLES
+ .XX +.03 +.5
.XXX + .015
SHT OF
SIZE
B
REV. DESCRIPTIONS DATE BY
A DOVER COMPANY
04/21/05
NONE
NONE
RICHARD RODRIGUEZ
POWER LINE
ACESS HOLE
WATER RETURN
CONNECTION (1-1/2" NPT)
WATER DISCHARGE
CONNECTION (1-1/2" NPT)
FILL PORT
(1" NPT) OVER FLOW
(1" NPT)
DRAIN PORT
(1/2" NPT)
MAIN CONTROL
ENCLOSURE
WATER LEVEL
VIEW PORT
1/2" WATER RETURN CONNECTION
(** NOT USED **)
1/2" WATER DISCHARGE CONNECTION
(** NOT USED **)
90.000
27.000 29.000 27.000
4.935
27.435 29.935
34.476
5.385
17.476 2X
22.579 2X
26.476
31.476 2X
PRESSURE GAUGES
6.500 2X
11.000 2X
13.388
2.000 2X
10.000 2X
10.000 2X
10.000 2X
2.000 2X
35.135 36.340
88.302
90.000
1.205
6.721
6.721
15MED CHILLER
CABINET ASSEMBLY
15RCU-801
2 2
