KLAMPING DIAGRAMS
Figure 1
Apply tape to jig with compression motion.
VAKuum Jig
Start
VAKuum Jig
End
Butt Joint
Figure 2
Completing the loop.
Baseplate with open gate.
Apply tape to both sides.
Vacuum
Figure 3
Straight Edge Jig with one gate closed and one open.
Closed gate
Open gate
Repair
Vacuum
VAK-Tape
Figure 4
The Straight Edge is held in place on the workpiece, which in
turn is held in place onto the work bench with the baseplate.
Workpiece
Work Bench
Straight Edge
One gate is closed on
the underside
Baseplate
VAK-Tape
Vacuum
