Q.V.P. EP1 User Manual
Quality vakuum products, inc, Instructions for ep1

Instructions for EP1
Foot Pedal
(Optional)
3/7/2000 - EP1
3/8“ I.D.
Tubing
Electric
Outlet
VAKuum Bag
VCA
The EP1 is assembled and ready to go. Screw the filter to the pump and attach the vacuum line to the
filter and barb. Attach the other end of the vacuum hose to either the vacuum bag or to your vacuum
clamp.
Keep the filter clean for best results. When using the EP1 with a vacuum bag, allow the pump to run
open for 2-3 mintues after the glue is set. This is to flush out any vapors that may remain in the
system.
11-1-02 Gast
ON/OFF
Switch
Filter
Gauge
Muffler
AC
Quality VAKuum Products, Inc.
OVER
74 Apsley St. - Hudson, MA 01749
Tel: 978-562-4680 - Fax: 978-562-4681
