Lexibook MFC110GB - Manual (Page 24)

24
SPECIFICATIONS
CPU 533MHz
Memory 128MB (Around 32MB used for operating system)
Storage 4GB (expandable up to 16GB)
LCD display 8” Digital TFT (800 x 480px)
Connector 2 x USB 1.1 ports, SD card reader (SDHC compatible), Ethernet port,
Microphone input, Headphone jack, AC power jack, Touch Pad
LAN Built-in 10/100 Mbit LAN,
Compatibility with the Lexibook WiFi USB key
Audio Built-in mono speaker
Battery 1 lithium battery (included) / 1500mAh, 7.4V
Battery life 3 hours (average)
Dimension 225 x 165 x 30 mm
Weight 0.8kg
Adaptor specifications: Input: 100V-240V~ 50/60Hz 0.8A
Output: 9.8V 2.5A
Short service time of battery
• Make sure the battery is fully charged.
• Make sure the battery is not used for an excessive long time after being fully charged.
• Recharge the battery before using it again.
• Due to the battery’s chemical properties, it’s normal that after frequent use, the battery’s
service time shortens.
• Any further questions, please contact the nearest service center.
After the Lexibook welcome screen, the laptop switch itself off/LCD blank screen
• Make sure the battery has enough power for the computer to start and operate normally.
• Plug the AC adapter to a main socket to charge the battery.
Built-in speaker doesn’t work
• Check the volume settings in the volume control panel.
• Earphones may be inserted into the computer.
Disconnection of SD card
• Check the connection between the equipment and the computer.
• Check if the computer interface configuration can satisfy the requirements of the devices, or if
they are compatible.
Is it possible to install a new program?
You can install new programs on your laptop if they are compatible with Windows CE 5.0 (those
programs are rare). But for security reasons Windows CE 5.0 will generally not allow new
applications. This will protect your laptop and prevent the unit from being infected by viruses.
