Revision 05-12 – BRAND Hydraulics HP STYLE HAND OPERATED PUMPS User Manual
Page 2
B
Certificate #02.002.1
ISO 9001:2000 WITH DESIGN
Revision 05-12
3/4" PIPE
RELEASE VALVE
#6 SAE OUTLET
BODY
TANK
FILL/
VENT PLUG
(1/4"
NPT)
ADJUSTABLE
R
ELIEF
MOUNTING BRACKET
22.
49" [5
71.2
]
16.
67" [4
23.5] 12
" TANK
SHOWN
2.88" [73.0]
4.00" [101.6]
DIMENSIONS LISTED ARE THE SAME FOR ALL THREE PUMP SERIES
(HP61DA AND HP121DA SHOWN)
15.
8" [401.3]
(12"
TA
NK
)
13.
8" [350.5]
(10"
TA
NK
)
11.
8" [299.7]
(8"
TA
NK
)
9.8
" [248.9]
(6" TA
NK
)
4X Ш0.39" [Ш9.92]
1/4
" NPT RE
TURN POR
T (RP, OPT
ION
AL)
Figure 2: Dimensional Data for Horizontal HP style hand pumps in inches & [millimeters].
