BRAND Hydraulics 34 SERIES SECTIONAL DIRECTIONAL CONTROL VALVES - Manual (Page 3)

Certificate #02.002.1
ISO 9001:2008 WITH DESIGN
Revision 10-12
DIMENSIONAL DATA: inches & [millimeters]
# OF
SPOOLS
L
1 5.87" [149.1]
2 7.25" [184.0]
3 8.62" [218.9]
4 10.00" [253.9]
5 11.37" [288.8]
6 12.75" [323.7]
7 14.12" [358.6]
8 15.50" [393.6]
9 16.87" [428.5]
10 18.25" [463.4]
11 19.62" [498.3]
12 21.00" [533.3]
Figure 1: Dimensional data for various Series 34 valve sections in inches & [millimeters].
Handles shown in standard position.
