General information, Dimensional data, Flow & pressure information – BRAND Hydraulics SDCF DIRECTIONAL CONTROL VALVES User Manual
Page 2
04/14
2.19" [55.6]
3.94" [100.0]
0.94" [23.8]
4
.3
2
"
[1
0
9
.8
]
2.24" [56.8]
3
.2
2
"
[8
1
.8
]
2
.1
3
"
[5
4
.0
]
RELIEF ADJUSTMENT
8
.8
"
[2
2
4
]
3X Ш0.27" [Ш6.7]
11.0" [278]
B PORT
A PORT
GENERAL INFORMATION:
Pipe Thread Sealant - Warranty is void when Teflon tape is used to seal pipe threads. This is because Teflon tape is a
friction reducing agent which allows customers to over-torque fittings. We recommend using a sealant that does not include
friction reducing agents i.e. Lead Plate.
Spool Information - All SDCF’s are built with Iosso plated spools to help prevent the spools from locking up when they are
in a corrosive environment. For highly corrosive environments, i.e. marine applications, we recommend using a stainless
steel spool. To order a valve with a stainless steel spool simply add “SS” to the end of the model code.
DIMENSIONAL DATA:
FLOW & PRESSURE INFORMATION:
0
34
69
103
138
172
207
3.8
11.4
22.7
34.1
45.4
56.8
68.1
75.7
0
500
1000
1500
2000
2500
3000
1.0
3.0
6.0
9.0
12.0
15.0
18.0
20.0
P
re
s
s
u
re
(b
a
r)
Flow (lpm)
P
re
s
s
u
re
(p
s
i)
Flow (gpm)
Pressure vs. Flow for Pilot Relief
SF391 Spring
Relief is set at 6 gpm (22.7 lpm)
0
3
7
10
14
17
21
24
28
31
3.8
11.4
22.7
34.1
45.4
56.8
68.1
75.7
0
50
100
150
200
250
300
350
400
450
1.0
3.0
6.0
9.0
12.0
15.0
18.0
20.0
P
re
s
s
u
re
(b
a
r)
Flow (lpm)
P
re
s
s
u
re
(p
s
i)
Flow (gpm)
Neutral Flow Pressure Drop
This curve represents the
pressure difference between
the inlet and the outlet.
TM Spool
