04/14

TROUBLESHOOTING:

Problem: Valve chatters or has stability issues. Instability generally occurs when the valve sees an application that has
rapidly changing loads. (ie: Fan, Vibration, etc.) Because of these changing loads the compensator spool tries to compensate
rapidly. This causes the valve to become unstable, as well as begin to make noises, including a chatter.

Solution: Most instability issues can be solved by using a different compensator spool. A replacement spool designed for
load changing applications can be ordered. (Part #: XDC609)

GENERAL INFORMATION:


Pipe Thread Sealant - Warranty is void when Teflon tape is used to seal pipe threads. This is because Teflon tape is a
friction reducing agent which allows customers to over-torque fittings. We recommend using a sealant that does not include
friction reducing agents i.e. Lead Plate.

DIMENSIONAL DATA:

FCR51 & FC51 DIMENSIONAL DATA (FCR51 SHOWN)






























2

.1

3

"

[5

4

.0

]

0.88" [22.4]

3.88" [98.4]

0.35" [8.9] REF.

Ш

9

32

" [Ш7.1] THRU

(2 PLACES)

2.30" [58.5] REF.

0.94" [23.8] REF.

1

.8

8

"

[4

7

.6

]

4

.9

4

"

[1

2

5

.6

]

5

.9

9

"

[1

5

2

.1

]

1.88" [47.6]

0.12" [3.2]

2.75" [69.8]
