Page 6
Toe Jack
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
MODEL:
J13060 - 3 Ton Capacity
6
Item
Part Number
Description
Qty
1
649-1-0060-407 Bolt
6
2
136-3-1108-109 Saddle Assy
1
3
136-6-5303-105 Roll Pillar
1
4
522-2-0206-104 Retaining Spring
2
5
115-6-1808-102 Retainer Ring
1
6
*
O-ring
1
7
136-6-1204-103 Guide Ring
1
8
*
O-ring
1
9
136-6-1107-105 Slide Track
2
10
N/A
Piston Rod
1
11
*
Back-up Ring
1
12
*
U-cup
1
13
599-7-0360-103 Guide Ring
1
14
136-5-5303-109 Roll Pillar
2
15
N/A
Base Assy.
1
16
649-1-0080-046 Bolt
1
17
*
Washer
1
18
511-2-0050-025 Spring
1
19
N/A
Steel Ball
2
20
*
Oil Seal
1
21
238-6-1701-403 Release Valve
1
Item
Part Number
Description
Qty
22
414-6-1216-107 Needle Valve
1
23
512-2-0067-010 Spring
1
24
*
O-ring
1
25
N/A
Valve Cap
1
26
414-6-1215-307 Screw
1
27
505-9-0092-207 Oil Filler Plug
1
28
518-4-0070-207 Pin
2
29
511-5-0012-016 Snap Pin
2
30
226-3-1300-102 Handle Sleeve Assy
1
31
226-4-1415-105 Pump Assy.
1
32
N/A
Pump Piston
1
33
*
O-ring
1
34
*
Oil Seal Assy
1
35
N/A
Pump Cylinder
1
36
*
O-ring
1
33
*
Washer
1
34
226-6-1402-108 Swivel Seat
1
35
181-3-2100-103 Handle Assy
1
*
136-3-9906-107 Repair Kit
1
(*) - Items available only as Seal Kit. Replacement requires special skills, knowledge, and equipment. Only an authorized
service center may perform the repair and/or replacement of these items.
N/A - Not user serviceable
