10
(*) - Items available only as Seal Kit. Replacement requires special skills, knowledge, and equipment. Only an authorized
service center may perform the repair and/or replacement of these items.
N/A - Not user serviceable
Toe Jack
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
MODELS: J13300 - 15 Ton Capacity
Item Part Number Description Qty
1 196-3-1600-101 Base Assy 1
2 324-4-1900-208 Filler Screw Assy 1
3 599-7-0700-101 Guide Ring 2
4 522-7-0700-207 U-cup 1
5 579-7-0700-206 Back-up Ring 1
6 196-6-1201-105 Ram Piston 1
7 511-7-0700-909 O-ring 1
8 511-7-0635-106 O-ring 1
9 196-6-1301-109 Guide Ring 1
10 G57-6-1209-101 Buckle Ring 1
11 G46-6-1301-205 Handle Sleeve 1
12 G62-6-1309-108 Linkage 1
13 196-3-1400-103 Piston Pump Assy 1
14 G62-6-1402-108 Bracket 1
15 515-3-0150-106 Copper Washer 1
16 566-4-0080-508 Link Pin 3
17 513-5-0016-018 Retaining Pin 3
Item Part Number Description Qty
18 238-4-1700-207 Release Valve Assy 1
19 601-7-0008-009 Steel Ball 2
20 503-9-0067-103 Spring Cap 1
21 644-1-0080-004 Screw 1
22 414-6-1216-107 Thimble 1
23 512-2-0067-010 Safety Spring 1
24 511-7-0080-400 O-ring 1
25 414-6-1215-307 Relief Screw 1
26 509-9-0145-109 Safety Valve Lid 1
27 512-2-0063-104 Compression Spring 1
28 601-7-0012-000 Steel Ball 1
29 552-2-0080-106 Compression Spring 1
30 532-3-0180-100 Combination Washer 1
31 A16-6-5006-104 Screw 1
32 522-2-0260-058 Return Spring 2
33 196-3-1100-101 Slider Assy 1
34 196-4-2100-102 Handle Assy 1
