SAFETY AND GENERAL INFORMATION
Save these instructions. For your safety, read, understand,
and follow the information provided with and on this device
before using. The owner and/or operator shall have an
understanding of the device, its operating characteristics and
safety operating instructions before operating the equipment.
The owner and/or operator shall be aware that use and repair
of this product may require special skills and knowledge.
Instructions and safety information shall be read to and
discussed with the operator in the operator's native language,
making sure that the operator comprehends their contents,
before use of this equipment is authorized. If any doubt exists
as to the safe and proper use of this device, remove from
service immediately.
Inspect before each use. Do not use if abnormal conditions
such as cracked welds, damaged, loose or missing parts are
noted. Any equipment that appears damaged in any way, is
found to be worn, or operates abnormally shall be removed
from service until repaired. If the equipment has been or is
suspected to have been subjected to an abnormal load or
shock, immediately discontinue use until inspected by a factory
authorized repair facility (contact distributor or manufacturer
for list of authorized repair facilities). It is recommended
that an annual inspection be made by an authorized repair
facility. Labels and Operator's Manuals are available from
the manufacturer.
PRODUCT DESCRIPTION
This product is designed to lift, position, or move, but not
sustain, rated capacity loads. It is not designed to be used as
a stand-alone device. Any load lifted, positioned, or otherwise
moved by this device, must immediately be supported by
appropriately rated mechanical means. A wide variety of
applications exist for this category of product. Special skill,
knowledge and training may be required for a specific task and
this product may not be suitable for all jobs listed. Unsuitable
applications include applications that call for a device to
lift, position, move or support persons, animals, hazardous
materials, mobile homes and dwellings in general, mirrors,
plate glass or to connect/secure hatches, components, and
materials between bulkheads. The user ultimately must make
the decision regarding suitability of the product for any given
task and therefore accept responsibility for that decision.
TECHNICAL SPECIFICATIONS
J13060 rated capacity: 6,000 lbs. (3 tons)
J13120 rated capacity: 12,000 lbs. (6 tons)
J13200 rated capacity: 20,000 lbs. (10 tons)
J13300 rated capacity: 30,000 lbs. (15 tons)
Hydraulic Pressure @ rated capacity:
J13060: 4185 psi
J13120: 4000 psi
J13200: 5400 psi
J13300: 7750 psi
PREPARATION
Before Use
1. Before using this jack, read the operator's manual completely
and familiarize yourself thoroughly with the product, its
components and recognize the hazards associated with
its use.
2. Verify that the product and application are compatible.
3. Assemble handle, ensure spring clips align with slots.
Replace reservoir oil plug with Vent Screw provided
4. To familiarize yourself with basic operation, use the notched
end of provided Pump Handle to engage and turn the
Release Valve:
a. Clockwise until firm resistance is felt to further turning.
This is the ‘ CLOSED’ Release Valve position used to
raise the ram plunger.
b. Counter-clockwise, but no more than 1/2 turn from
the closed position. This is the ‘ OPEN’ Release Valve
position used to lower the Ram Plunger.
5. With Ram Plunger fully retracted and release valve closed,
pump the operating handle. If Ram Plunger responds
immediately, jack is ready for use. If jack does not respond,
follow Bleeding/Venting Trapped Air instruction below.
6. Check that the pump operates smoothly and that the
Extension Screw will thread up/down easily before
putting into service. Replace worn or damaged parts and
assemblies with Omega authorized replacement parts only.
Bleeding/Venting Trapped Air
With the Release Valve in the OPEN position (step 4b above)
and with Ram Plunger fully lowered, locate and remove the
Oil Filler Plug/Screw. Insert the Pump Handle into the Handle
Sleeve; then pump 6 to 8 full strokes. This will help release
any pressurized air which may be trapped within the reservoir.
Oil level should be even with the bottom of the oil filler hole.
Reinstall oil reservoir Vent Screw.
• Study, understand, and follow all instructions before
operating this device.
• Do not exceed rated capacity.
• Use only on hard level surfaces.
• Lifting device only. Immediately after lifting, support
load with appropriate means.
• Lift only on those areas of a vehicle as specified by the
vehicle manufacturer.
• No alterations shall be made to this product.
• Only attachments and/or adapters supplied by the
manufacturer shall be used.
• Failure to heed these markings may result in personal
injury and/or property damage.
! WARNING
