4 w w w.bk prec ision.c om
Digital Storage Oscilloscopes
Models 2530B and 2532B
v030612
Specifications
M ode l 2530B 2532B
Pe rformance Characteris tics
Bandwidth 25 MHz 40 MHz
Real Time Sampling Rate
Single Channel: 500 MSa/s
Dual Channel: 250 MSa/s (for timebase faster
than 250 ns/div)
Channels 2
Rise time <14 ns <8.8 ns
Record Length
32,000 points when time base is 50 ns or 25 ns at maximum data
depth (16,000 points for 50 s - 100 ns time base), 16,000 points
for dual channel operation
Vertical Resolution 8 bit
Vertical Sensitivity 2 mV/div -10 V/div(1-2-5 order)
DC Gain Accuracy
<±3.0%: 10 mV/div to 10 V/div in Fixed Gain Ranges
<±4.0%: 2 mV/div ,5 mV/div and Variable Gain Ranges
Maximum input voltage 400 V (DC+AC pk-pk, 1 MΩ input impedance, X10), CAT I
Position Range
2 mV–100 mV: ±2 V
102 mV - 5 V: ±40 V
Horizontal Scan Range
25 ns/DIV - 50 s/DIV
Scan mode: 100 ms/DIV - 50 s/DIV
(1 - 2.5 - 5 sequence)
10 ns/DIV - 50 s/DIV
Scan mode: 100 ms/DIV -
50 s/DIV (1 - 2.5 - 5
sequence)
Timebase Accuracy ±100 ppm measured over 1ms interval
Input Coupling AC, DC, GND
Input Impedance 1 MΩ±2% || 16 pF±3 pF
Vertical and Horizontal Zoom
Vertically or horizontally expand or compress a live or
stopped waveform
I/O interface
USB host port on front panel supports USB flash drives
RS-232 and USB device port for connection to PC
Pass/Fail output
A cquis ition Mode s
Sample Display sample data only
Peak Detect Capture the maximum and minimum values of a signal
Average Waveform averaged, selectable from 4, 16, 32, 64, 128, 256
Scan Mode For time base settings 0.1 s/div - 50 s/div
T rigger System
Trigger Types
Edge, Pulse Width, Video*, Slope, Alternating
*Support signal Formats: PAL/SECAM, NTSC
Trigger condition : odd field, even field, all lines, or line number
Trigger Modes Auto, Normal, Single
Trigger Coupling AC, DC, LF reject, HF reject
Trigger Source CH1, CH2, EXT, EXT/5, AC Line
Pulse Width Trigger
Trigger Modes: (>,<,=) Positive Pulse Width,
(>,<,=) Negative Pulse Width
Slope Trigger
(>,<,=) Positive slope, (>,<,=) Negative slope
Time: 20 ns -10 s
H ardware Freque ncy Counte r
Reading Resolution 6 Bytes
Accuracy ±0.01%
Range DC Couple, 10 Hz to 25 MHz
Signal Types
All trigger signals (except pulse width trigger
and video trigger)
Wave form Math and Me as ure
Math operation Add, Subtract, Multiply, Divide, FFT
FFT
Window mode: Hanning, Hamming, Blackman, Rectangular
Sampling points: 1024
Measure
Amplitude, Average, Base, Burst Width, Cyclic RMS,
+ Duty Cycle, - Duty Cycle, Fall Time, Frequency, Max, Mean,
Min, Rise Overshoot, Fall Overshoot, Rise Preshoot, Fall
Preshoot, Peak-Peak, Period, Phase, Rise Time, RMS, Top, +
Width, - Width, plus 8 advanced parameters for edge to edge
timing measurements
D isplay Syste m
Display 5.7 in. Color TFT, 320 x 240 resolution, 64K color
Display Contrast (Typical state) 150:1
Backlight Intensity (Typical state) 300 cd/m
2
Display Area 8 x 12 div
Display Mode Dots, Vector
Persistence Off, 1 sec, 2 sec, 5 sec, Infinite
Menu Display Timer 2 sec, 5 sec, 10 sec, 20 sec, Infinite
Screen-Saver
Off, 1 min, 2 min, 5 min, 10 min, 15 min, 30 min,
1 hour, 2 hour, 5 hour
Waveform interpolation Sin(x)/x, Linear
Display Color Mode Normal , Invert
Power Requirements 100-240 VAC, CAT II, 50 VA max, 45 Hz to 440 Hz
E nvironment
Temperature
Operating: 50° F to 104 °F (10 °C to 40 °C)
Not operating: -4 °F to 140 °F (-20 °C to 60 °C)
Humidity
Operating: 85% RH, 104 °F (40 °C)
Not operating: 85% RH, 149 °F (65 °C)
Altitude
Operating: 9,842 ft (3,000 m)
Not operating: 50,085 ft (15,266 m)
G eneral
Dimension (WxHxD) 12 x 6.3 x 5.2 inches (305 x 160 x 133 mm)
Weight 5 lbs. (2.3 kg)
Warranty
2530B One Year
2532B Three Years
Included accessories: User Manual, 10:1 Probe Set (2 pieces), Power Cord, USB Interface Cable,
EasyScope Software Installation Disk
