Front panel features
Digital Storage Oscilloscopes
Models 2530B and 2532B
Co mmunicatio n
RS232 and USB ports enable remote PC control
via EasyScope PC software.
Security l oop
Use the built-in security loop to secure your
instrument to your location.
Rear panel
Display
5.7” color display.
M enu On/Off butto n
Configure the menu parameters
and hide the menu with the
push of a button to view your
signal in full screen.
USB h ost port
Connect your USB flash drive to
conveniently update firmware and
store/recall waveform data, setups,
and screenshots.
Wavefo rm analysis wi th math an d FFT
Analyze your signals with add, subtract,
multiply, and divide functions. View the
signal’s frequency spectrum and perform
harmonic distortion analysis.
Advanced t ri ggerin g
Isolate the signal with
advanced triggering
including pulse width and
selectable video trigger.
Auto s etup
Vertical, horizontal, and
trigger controls are
automatically adjusted for
fast signal display.
Prin t butto n
Simply press the Print button
to save a screenshot in bitmap
format to a USB flash drive.
Co nte xt sens itiv e he lp feature
While in help mode, push any button
and a help window will pop up
describing the functionality.
