4
Dimensions
195 x 78.5 x 191.5mm
(7.68
" x 3.09 " x 7.54 " )
Weight
Net: 0.7 kg (1.5 lbs);
Gross: 1 kg (2.2 lbs) -- blister card;
2.3 kg (5 lbs) -- blow mold case
Cable reach
1m (3 ') -- expandable to 5m (16 ')
w/optional extensions
Imager head
diameter 16mm (0.63") / 8.5mm (0.33") is standard;
5.5mm (0.22") is optional
Waterproof Imager head and cable to 3m (10')
Operating temp.
Main unit: 32°F to 113°F (0°C to 45°C);
Cable: 14°F to 176°F (-10°C to 80°C)
Storage temp. -4°F to 158°F (-20°C to 70°C)
Operating
humidity
5% to 95% non-condensing (display unit)
Video output RCA
2.3 Accessories Included
1) User’s Manual
2)
Imager head and cable – 16mm, 8.5mm and 5.5mm diameter imager
head
3) Magnet, hook and mirror (Optional)
4) Video-out cable
5) 4 x AA batteries
6) Blister case or blow molded case -- there are two different packages
for the tool.
2.4 Tool Components
The MaxiVideo™ MV101 comes with the following items. Here
16mm diameter imager head and its matching accessories -- magnet,
hook and cable are shown below as an example.
Note: Because of continuing improvements, actual product may
differ slightly from photo.
