10
Fig. 9 Fig. 10
For MV101 (with 8.5mm imager head):
The three accessories include magnet, hook and mirror (Fig. 3). All
are attached to the imager head in the same manner. Hold the
accessory and the imager head as shown in Fig. 11, slip the end of the
accessory over the imager head and then fix the accessory as shown in
Fig. 12.
Fig. 11 Fig. 12
For MV101 (with 5.5mm imager head):
The two accessories include magnet and mirror (Fig. 4). All are
attached to the imager head in the same manner. Hold the accessory
and the imager head as shown in Fig. 13, screw the thread part of the
accessory over the imager head and then fix the accessory as shown in
Fig. 14.
