Atec Tenney-T10C Series - Manual (Page 3)

Humidity capability: 20% to 98% RH in the dry bulb
range of +20°C or +85°C as limited by a 3°C dew
point. Test data based on 24°C ambient, sea level, 60
Hz. On 50 Hz or higher than 24°C, ambient
performance may be reduced. Consult factory
regarding any special cooling requirements.
Model Non-
humidifi ed
T40S-2 T40C-4 T40C-6 T64S-7.5 T64C-6 T64C-15
Humidifi ed T40RS-2 T40RC-4 T40RC-6 T64RS-7.5 T64RC-6 T64RC-15
Workspace W 40(1016) 48(1219)
D 44(1118) 48(1219)
H 40(1016) 48(1219)
Exterior W 66(1676) 72(1829)
D 73.5(1867) 81.5(2070)
H 80.25(2038) 91(2311)
Temperature & Humidity
Low °C -40 °C -73 °C -73 °C -40 °C -73 °C -73 °C
High °C +200 °C +200 °C +200 °C +200 °C +200 °C +200 °C
Change Rates in Minutes
Time starting at
Ambient to listed
temperature.
Based on empty
chamber. 200 °C 35 45
150 °C 25 30
93 °C 10 15
65 °C 5 10
0 °C 5 5
-18 °C 20 — — 10 10 —
-40 °C 120 — — 25 30 —
-54 °C — 45 40 — 45 20
-65 °C — 60 50 — 65 35
Live Load Capacity in Watts (Humidity System Off)
Temperature +10 °C
-18 °C 1000 — — 4500 — —
-40°C 100 — — 1000 — —
-54 °C — 1200 2000 — 1200 4000
-65 °C — 900 1500 — 800 2500
Utilities, etc
Refrigeration (1) 2 HP (2) 2 HP (2) 3 HP (1) 7.5 HP (2) 3 HP (2) 7.5 HP
Heater Capacity 6 6 6 8 8 8
Humidifi er KW 2 2 2 2 2 2
GPH 1 1 1 1 1 1
AMPS 230V. 1 Ph 230V. 1 Ph 230V. 1 Ph 230V. 1 Ph 230V. 1 Ph 230V. 1 Ph
S & C RC & RS 41 50 50 50 38 46 71 80 57 65 71 80
Fuse 50 60 60 60 60 70 100 110 70 80 100 110
Unit Weight LBS. 2740 3540
40 and 64 cubic foot models
Overall dimensions in inches (mm) for the 40 and 64 cubic foot models:
Gruenberg, Blue M, Tenney, Lunaire
Mailing Address: P.O. Box 150 | White Deer, PA 17887-0150 | USA |
Phone: (570) 538-7200 | Fax: (570) 538-7380
Physical Address: 2821 Old Route 15 | New Columbia, PA 17856-9396
[email protected]
tps-tenney-classic-series-temperature-and-humidity-cycling-chambers-20100129
