Options:
• IEEE interface
• LinkTenn software for Windows
®
• RS-422, 423, 232 or 485 interface assemblies
• 6-event relay board at 1 amp each
• Water demineralizer
• Water reservoir for humidity system (5 gallon)
• Recirculating system for humidity water
• Viewing window, thermally insulated and heated
• Interior light
• Shelving, adjustable and removable
• Water-cooled refrigeration system
• Alternate power supply wiring
• Automatic CO2 or LN2 cooling boost system
• Additional ports, gloves, etc.
• 5” or 6” rubber tire casters (3” phenolic casters are standard)
• GN2 purge system
• Refrigeration taps and pressure gauges
• Remote console for instrumentation
• Recording instruments
• Redundant thermal protection and alarm system
• External dryer for obtaining humidity as low as 5% (to 20°C)
• Alternate refrigeration and/or heating systems for faster
temperature change rates or increased product load handling
capabilities
10, 20, and 30 cubic foot models
Overall dimensions in inches (mm) for the 10, 20, and 30 cubic foot models:
Model Non-
humidifi ed
T10S
T10C
T20S1.5
T20C-3
T20C-4
T30S
T30C
Humidifi ed
T10RS
T10RC
T20RS1.5
T20RC-3
T20RC-4
T30RS
T30RC
Workspace
W
24(610)
30(762)
36(914)
D
27(686)
32(813)
40(1016)
H
28(711)
36(914)
36(914)
Exterior
W
30(762)
41(1041)
46(1168)
D
47(1194)
55(1397)
64(1625)
H
74(1880)
84(2134)
84(2134)
Temperature & Humidity
Low
°C
-40°C
-73°C
-40°C
-73°C
-73°C
-40°C
-73°C
High
°C
+200°C
+200°C
+200°C
+200°C
+200°C
+200°C
+200°C
Change Rates in Minutes
Time starting at
Ambient to listed
temperature. Based
on empty chamber.
200°C
30
30
60
60
60
70
70
150°C
20
20
40
40
40
50
50
93°C
15
15
25
25
25
25
25
65°C
10
10
15
15
15
15
15
0°C
10
5
40
10
5
40
10
-18°C
20
10
60
15
10
60
15
-40°C
60
20
90
30
20
90
25
-54°C
—
25
—
40
25
—
35
-65°C
—
35
—
50
35
—
50
Live Load Capacity in Watts (Humidity System Off)
Temperature
+10°C
600
1275
600
1200
1800
600
1600
-18°C
450
1000
450
1000
1500
500
1400
-40°C
100
850
100
850
1275
250
1200
-54°C
—
600
—
700
1050
—
1000
-65°C
—
400
—
500
750
—
700
Utilities, etc
Refrigeration
(1)1.5HP
(2)1.5HP
(1) 1.5HP
(2) 1.5HP
(2) 2HP
(1) 2HP
(2) 2HP
Heater Capacity
2.5 KW
2.5 KW (3 KW If 208 Option)
Humidifi er
KW
1 KW
2 KW
GPH
0.5
1
AMPS @ 230V. 1 Ph
28
30
32
34
35
34
35
AMPS Fuse
35
40
45
Unit Weight
LBS.
850
950
1250
1350
1400
1500
1500
Humidity capability: 20% to 98% RH in the
dry bulb range of +20°C or +85°C as limited
by a 3°C dew point. Test data based on 24°C
ambient, sea level, 60 Hz. On 50 Hz or higher
than 24°C, ambient performance may be
reduced. Consult factory regarding any
special cooling requirements.
