SPECIFICATIONS AND TOLERANCES

ELECTRICAL (

PER

IEC 1000-4-4)

Burst Polarity:

Positive, negative, alternating

Burst Voltage:

200V to 4.4kV

Burst Voltage
Resolution:

Burst Voltage

±10% of setting ÷ 2 with

Tolerance:

Ω

load, ±20% of setting

with no load

Burst Frequency:

Adjustable from 1kHz to 1MHz
up to 4.4kV

Burst Duration:

1.0ms to 20ms; 1.0ms
resolution or 1 to 200 pulses

Period Between

Adjustable from 300ms to 5s;

Bursts:

1ms resolution

Burst Test Length:

1 to 360 sec.; 1 sec. resolution
1 to 240 min.; 1 min. resolution
1 to 24 hours; 1 hour resolution

Wait Time

1 to 360 sec.; 1 sec. resolution

Between Tests:

1 to 240 min.; 1 min. resolution
1 to 24 hours; 1 hour resolution

Voltage Monitor:

Built-in; 150MHz bandwidth

Note:

For any combination of
frequency, duration and period,
the number of pulses cannot
exceed 600 per second and
200 per burst.

HYSICAL

Height:

21cm (8

”)

Width:

21cm (8

”)

Depth:

52cm (20

”)

Weight:

11.4kg (25 lbs.)

INIMUM

YSTEM

EQUIREMENTS

E100 series control center and
E000 blank plug-in module (If no other half-width
module is ordered)

Model E411

ECAT: AN EXTRAORDINARY CONCEPT IN EMC
TESTING FOR VULNERABILITY TO SURGE,
EFT AND POWER QUALITY.

ECAT is a totally integrated and modularized system
which offers unprecedented testing ease, accuracy and
versatility to manufacturers, test houses, and anyone
who will be testing for effects of Pulsed EMI.

ECAT is designed to test products according to a broad
range of international standards developed by ANSI,
the IEC, CENELEC and other agencies. The European
Norms, developed by CENELEC, became mandatory
on January 1, 1996 for all equipment shipped into the
European Union or shipped across EU borders.

KPS-510B-11/97

A division of Thermo Voltek, a Thermo Electron company

KeyTek and ECAT are registered trademarks and BurstWare, EFT/Noise, and PQF are
trademarks of Thermo Voltek Corporation. ©Thermo Voltek. Specifications are subject
to change without notice. Printed in USA.

One Lowell Research Center
Lowell, Massachusetts 01852-4345 USA
1 800 753 9835 • Tel: 1 978 275 0800 • Fax: 1 978 275 0850
email: [email protected]
http://www.keytek.com

For additional ECAT

product literature call, email or

fax the KeyTek sales department.

AVAILABLE OPTIONS

E411-CH

Chirp capability – provides an output in
which the amplitude increases and the
frequency decreases during the burst,
similar to actual EFT events.

E411-2MHz: Hardware option to provide burst

frequency operation to 2MHz,
at voltages to 3kV.

CCL-4:

A covered, safety-interlocked capacitor
clamp for coupling the burst to I/O lines
(including data and signal lines). All
clamp surfaces are nickel-plated and
the hinges are nickel-plated, beryllium
copper finger-stock to insure excellent
RF performance over time.

CCL-4/S:

A covered, safety-interlocked capacitor
clamp for coupling the EFT/Noise

™

burst into I/O lines (including data
and signal lines).
