100 ms integration time approximately 76 sec (typical)
10 ms integration time approximately 25 sec (typical)
5 cycle integration time approximately 16 sec (typical)
100 cycle integration time approximately 25 sec (typical)

CROSS-CHANNEL AMPLITUDE/PHASE ACCURACY
Ch. 1 range = Ch. 2 range: ±0.04 dB
±0.5 deg

Abbreviations
Zoom mode = Start frequency >0 Hz
dBVrms = dB relative to 1 Volt rms.
dBfs = dB relative to full scale amplitude range.
Full scale is approx. 2 dB below ADC overload.
FS is fs = Full Scale; synonymous with Input Range.
RS = Resistance of source or termination connected to
Agilent 35665A's input (from high to low).
Vs = voltage applied to Agilent 35665A''s input.
Vpk = Peak of the ac Voltage
Rload = Load resistance connected to Agilent 35665A's source
CF = center frequency
Typical = typical, non-warranted, performance
specification included to provide general product information
