Automatic Setup
Auto Setup Automatically sets timebase, trigger, and sensitivity to display a wide range of repetitive signals.
Vertical Find Scale Automatically sets the vertical sensitivity and offset for the selected channels to display a waveform with maximum dynamic range.
Probes
Probes (2) PP005A standard; Optional passive and active probes available.
Probe System: Probus Automatically detects and supports a variety of compatible probes.
Scale Factors Automatically or manually selected depending on probe used.
Color Waveform Display
Type Color 10.4" flat-panel TFT-LCD with high resolution touch screen
Resolution SVGA; 800 x 600 pixels
Real time Clock Dates, hours, minutes, seconds displayed with waveform. SNTP support to synchronize to precision internet clocks.
Number of Traces Display a maximum of 8 traces. Simultaneously display channel, zoom, memory, and math traces.
Grid Styles Auto, Single, Dual, Quad, Octal, XY, Single + XY, Dual + XY
Waveform Styles Sample dots joined or dots only
Analog Persistence Display
Analog & Color-Graded Persistence Variable saturation levels; stores each trace’s persistence data in memory.
Persistence Selections Select analog, color, or three-dimensional.
Trace Selection Activate persistence on all or any combination of traces.
Persistence Aging Time Select from 500 ms to infinity.
Sweeps Displayed All accumulated, or all accumulated with last trace highlighted
Zoom Expansion Traces
Display up to 4 Zoom and 4 Math/Zoom traces;
8 Math/Zoom traces available with XMAP (Master Analysis package) or XMATH (Advanced Math package).
CPU
Processor Intel 1.7 GHz or better with MS Windows 2000 Platform
Processing Memory Up to 1 Gbyte
Internal Waveform Memory
M1, M2, M3, M4 Internal Waveform Memory (store full-length waveforms with 16 bits/data point)
or store to any number of files limited only by data storage media
Setup Storage
Front Panel and Instrument Status Store to the internal hard drive, floppy drive or to a USB-connected peripheral device.
Interface
Remote Control Via Windows Automation, or via LeCroy Remote Command Set
GPIB Port (Optional) Supports IEEE – 488.2
Ethernet Port 10/100Base-T Ethernet interface
Floppy Drive Internal, DOS-format, 3.5” high-density
USB Ports 4 USB ports support Windows compatible devices
External Monitor Port Standard 15-pin D-Type SVGA-compatible
Parallel Port 1 standard
Auxiliary Output
Signal Types Select from calibrator or control signals output on front panel
Calibrator Signal 5 Hz – 5 MHz square wave or DC level; 0.0 to 5.0 V into 50 Ω (0-1 V into 1 MΩ) or TTL volts (selectable)
Control Signals Trigger enabled, trigger out, pass/fail status
Auxiliary Input
Signal Types Selected from External Trigger or External Clock input on front panel
General
Auto Calibration Ensures specified DC and timing accuracy is maintained for 1 year minimum
Power Requirements 100–120 VAC at 50/60/400 Hz; 200–240 VAC at 50/60 Hz; Automatic AC Voltage selection
Power consumption: < 800 VA
Environmental
Temperature (Operating) +5˚C to +40˚C including floppy disk and CD-ROM drives
Temperature (Non-Operating) -20 ˚C to +60˚C
Humidity (Operating) 5% to 80% relative humidity (non-condensing) up to +30 ˚C. Upper limit derates to 25% relative humidity (non-condensing) at +40˚C
Humidity (Non-Operating) 5% to 95% relative humidity (non-condensing) as tested per MIL-PRF-28800F
Altitude (Operating) up to 10,000 ft (3048 m) at or below +25 ˚C
Altitude (Non-Operating) up to 40,000 ft (12,192 m)
Random Vibration (Operating) 0.31 g rms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Random Vibration (Non-Operating) 2.4 g rms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Functional Shock 20 g peak, half sine, 11 ms pulse, 3 shocks (positive and negative) in each of three orthogonal axes, 18 shocks total
Physical Dimensions
Dimensions (HWD) 264 mm x 397 mm x 491 mm; 10.4” x 15.6” x 19.3” (height excludes feet)
Weight 18 kg; 39 lbs.
Shipping Weight 24 kg; 53 lbs.
Certifications
CE Approved, UL and cUL listed; conforms to EN 61326-1, EN 61010-1, UL 3111-1, and CSA C22.2 No. 1010.1
Warranty and Service
2-year warranty; calibration recommended annually. Optional service programs include extended warranty, upgrades, and calibration services
Specifications
