General
Specifications
Power Requirements
117 V ac @ 0.35 amps or 220 V ac @
0.2 amps, 50 to 400 Hz
Maximum Power Dissipation: 20 W
Line Voltage Stability: 105 to 130 V ac
Fuse: 0.5 amp, fast-blow (requires an IEC
standard 3-prong grounded AC plug)
Dimensions
4.5 in. (11.4 cm) H
Probe
Specifications
Options
Accessories
13.3 in. (33.8 cm) W
10.0 in. (25.4 cm] D
Weight
18 lb (6.1 kg)
Environmental Requirements
Instrument Operating Temperature: 50º F
to 110º F (10º C to 43º C)
Instrument Storage Range: 0º F to 150º F
(-18º C to 65º C)
Temperature Range: -100°F to 300°F
(-70°C to 150°C)
Operating Pressure Range: vacuum of
29 in. Hg to 500 psig
.
220 V ac input power configuration
.
Display in metric engineering units
l RS-232 digital output
Optical Probe Extenders: Precision
lens systems that permit operation of Stan-
dard probes at a greater standoff distance
with no loss of probe sensitivity or fre-
quency response.
Fixture Stands: Proridcs a stationary
mounting for probes of any size.
Display
Meter Readout: 4.5-digit green vacuum
fluorescent, updates 4 times per second
Bargraph: 20-element green LED (0.5-volt
step size), 10 Hz response
Displacement Measurements
Output Signal: 0 to ±10 V dc,
output impedance
Switchable Offset Range: 0 to -15 V
Stability at 12 hrs. ±2° F (-1° C):
Drift less than 1.0% of full scale
Stability at 60° to 95° F (16° C to 35° C):
Drift less than 2.0% of full scale
Vibration Measurements
Output Signal: 0 to ±10 V dc full-scale
range, output impedance
Accuracy: Within 1.0% for peak-to-peak
readings from 1 Hz to 150 kHz
System Noise: Dependent upon probe type
and surface reflectivity
Tip Length: 3 in. (76.2 mm]
Cable Length: 54 in. (1372 mm] standard
l Bent probe tips
l High-pressure/high-vacuum probes
.
Wide-temperature-range probes from
-310°F to 1382°F (-190°C to 750°C)
Calibration Fixture: Secures the probe
and calibrates the instrument to a nonrotat-
ing target, utilizing a precision micrometer.
Can be used for initial calibration, calibra-
tion to a fluid medium, or
in-place calibra-
tion checks.
MTI Instruments: Pioneers in fiber-optic sensor technology
MTI has been in the forefront of noncontact
instrument on-line. For price information or
measurement technology for over 25 years. assistance with your application, call us
Our experienced application engineers are toll-free:
prepared to help you determine the best
solution to you mcasurement
problems,
l-800-342-2203.
before and after the sale.
MTI’s quick-turnaround maintenance and
repair services are available to keep your
MTI Instruments Inc.
325 Washington Avenue Extension
.
Albany, NY 12205
Phone: (518) 218-2550 l FAX: (518) 218-2506
