SeaSPY Magnetometer

Overhauser Sensor

Omnidirectional sensor that does not contain any consum-
able parts.

Electronics Module

Contains all of the driving electronics and Larmour counter.

Leak Detector

A visual queue and alarm sound when even a drop of water
gets inside the mag.

Depths Available

1000m (1500psi), 3000m (5000psi), 6000m (9000psi)

Tow Cable

The cable is made up of one twisted pair of conductors, a Vectran
strength member, water block and yellow poly-urethane jacket.
Length determined by customer.

Isolation Transceiver

Provides the complete interface between the PC and the mag. It
provides two-way digital communication along the same conductors
that power the mag. It also conditions the mag’s power supply.
Dims: 11 x 6 x 3 cm (4 x 2 x 1") Weight: 130g (0.28 lbs)

Power Supply

Accepts any AC line 48V power, from 100-240VAC and 50/60Hz to
provide conditioned and clean 24V DC power.
Dims: 11x 6 x 3.5cm (4 x 2 x 1") Weight: 165g (0.36 lbs)

Battery Clip Cable

Use this cable instead of the power supply. The mag’s total power
consumption is only 3W. A single 12V car battery
can power it for days.

RS232 Cable

Connects the mag and PC.

BOB

Data acquisition and visualization software.

Reusable Aluminum Shipping Case

Holds all accessories listed above.

Options

Pressure Sensor

Altimeter

Transponder

Side Scan , ROV & AUV Integrations

Deck Cable

Tow Cable Termination Kit

FreeWheel Wireless Cable Spool

Specifications

[email protected]

+1 905 479 9727 | marinemagnetics.com

A SeaSPY Magnetometer

System consists of:

Performance

Operating Zones

NO RESTRICTIONS

SeaSPY will perform exactly according

to spec. throughout the entire range

Absolute Accuracy

0.1nT

Sensor Sensitivity

0.01nT

Counter Sensitivity

0.001nT

Resolution

0.001nT

Dead

Zone

NONE

Heading Error

NONE

Temperature Drift

NONE

Power Consumption

1W standby, 3W maximum

Range

18,000nT to 120,000nT

Gradient Tolerance

Over 10,000nT/m

Sampling Range

4Hz – 0.1Hz

Communications

RS-232, 9600bps

Power Supply

9V-30V or 100-240 VAC

Towfish

Towfish Length

119 cm (47 inches)

Towfish Diameter

7.6 cm (3 inches)

Towfish Weight in Air

12kg (27 lbs)

Towfish Weight in Water

4kg (9 lbs)

Tow Cable

Conductors

Twisted pair

Breaking Strength

2,500 kg (5,500 lbs)

Outer Diameter

1 cm (0.4 inches)

Weight in Air

125 g/m (84 lb/1000 ft)

Weight in Water

44 g/m (29.5 lb/1000 ft)

Cable Termination

Field Replaceable

Floatation Cable

Outer Diameter

1.9 cm (0.74 inches)

Weight in Air

125 g/m (0.084 lbs/ft)

Weight in Water

-20 g/m (0.03 lbs/ft)
