TECHNICAL SPECIFICATIONS

Coupling

CDN Inputs

Banana socket front panel

5 connectors

CDN Output

Banana socket front panel

5 connectors

Waveforms

EFT/Burst

Surge Combination Wave

Ring Wave

IEC/EN 61000-4-4 Ed. 3

IEC/EN 61000-4-5 Ed. 3

IEC/EN 61000-4-12 Ed. 2, C 62.41

Maximum EFT/Burst Input Voltage

5kV

Maximum Surge Combination Wave
Input Voltage

7kV

Maximum Ring Wave Input Voltage

7kV

Coupling Path Selection

Automatic

IEC + ANSI

Synchronization

10V to 480V input voltage
0° to 359°, step 1°

Sync. on coupling path,
output BNC rear panel


Decoupling

Voltage AC

Up to 480V AC
16.7Hz, 50Hz, 60Hz

Voltage DC

Up to 480V DC

Nominal Current

32A

EFT/Burst Input Voltage Range

0.2kV - 5kV

Surge Combination Wave Input
Voltage Range

0.2kV - 7kV

Ring Wave Input Voltage Range

0.2kV - 7kV

Coupling Path Selection

Automatic

Synchronization

10V to 480V input voltage
0° to 359°, step 1°



Interfaces

Extension Connector
(37 pol. Sub-D connector)

Warning on AXOS Display

LEDs

Indication of coupling path Power ON LED
CDN active LED
