4 AXOS
tecHnicaL speciFications
GENERAL DATA
Control power
85 V - 264 V
50/60 Hz Dimensions
(W x H x D) 19“ / 4U
(45 x 18 x 49 cm)
User test storage unlimited Weight 30 kg
Remote interface Ethernet, RJ45 USB for USB memory stick
Display 7“ / 800x480 / 24 bit
with touch-screen AUX. interface D-sub 37p for external
CDN, external transfor-
mer etc.
External trigger
input 5 V TTL Synch input BNC, 10 V – 264 V AC
Trigger output 5 V TTL External start / stop
input 5 V TTL, starts / stops
predefined test sequence
EUT failed input 5 V TTL Analog output 0 – 10 V, for use with
external options
Warning lamp
output 2 x 24 V / 1 A DC Safety circuit stops the test when
unlocked
ICE / EN 61000-4-4 EDITION 2 EFT / BURST
Output voltage
0.2 – 5.0 kV ±10% at co-
axial output Spike frequency 1 Hz – 1 MHz
Polarity pos / neg / alternate Burst duration 10 us – 1 s
Output impedance 50 Ohms Burst period 1 ms – 10 s
Rise time 5 ns ±30% Test time 1 s– 999 minutes
Impulse duration 50 ns ±30% at 50 Ohm
50 ns –15 +100 ns at 1000
Ohm Trigger automatic, manual,
external trigger input
Burst mode normal, continuous, real,
random Integrated single
phase coupling /
decoupling network 264 V AC / 16 A
220 V DC / 10 A
