FRAX 150
Sweep Frequency Response Analyzer
Test Object Browser — Unlimited number
of tests and sweeps. Full user control. Quick Select Tabs — Quickly change
presentation view for different
perspectives and analysis tools. Quick Graph Buttons — Programmable
graph setting lets you change views quickly
and easily.
Sweep/Curve Settings — Every sweep
can be individually turned on or off,
change color, thickness and position. Dynamic Zoom — Zoom in and
move your focus to any part of
the curve. Operation Buttons — All essential functions
at your fingertips; select appropriate
function keys on screen with mouse.
Automated analysis compares two curves using
an algorithm that compare amplitude as well as
frequency shift and lets you know if the difference
is severe, obvious, or light.
Built-in-decision support is provided by using a built-in
analysis tool based on the international standard DL/T 911-2004.
