5 Fluke Corporation Fluke 1730 Three-Phase Electrical Energy Logger
Auxiliary inputs
Number of inputs
2
Input range
0 to ± 10 V dc, 1 reading/s
Scale factor (available 2014)
Format: kx + d user configurable
Displayed units (available 2014)
User configurable (7 characters, for example, °C, psi, or m/s)
Environmental specifications
Operating temperature
-10 °C to +50 °C (14 °F to 122 °F)
Storage temperature
-20 °C to +60 °C (−4 °F to 140 °F)
Operating humidity
10 °C to 30 °C (50 °F to 86 °F) max. 95 % RH
30 °C to 40 °C (86 °F to 104 °F) max. 75 % RH
40 °C to 50 °C (104 °F to 122 °F) max. 45 % RH
Operating altitude
2000 m (up to 4000 m derate to 1000 V CAT II/600 V CAT III/300 V CAT IV)
Storage altitude
12,000 m
Enclosure
IP50 in accordance with EN60529
Vibration
MIL 28800E, Type 3, Class III, Style B
Safety
IEC 61010-1: Overvoltage CAT IV, Measurement 1000 V CAT III/600 V CAT IV,
Pollution Degree 2
EMI, RFI, EMC
EN 61326-1: Industrial
Electromagnetic compatibility
Applies to use in Korea only. Class A Equipment (Industrial Broadcasting and
Communication Equipment)
Radio frequency emissions
IEC CISPR 11: Group 1, Class A
Temperature coefficient
0.1 x accuracy specification/°C
General specifications
Color LCD display
4.3-inch active matrix TFT, 480 pixels x 272 pixels, resistive touch panel
Warranty
1730 and power supply: Two-years (battery not included)
Accessories: One-year
Calibration cycle: Two-years
Dimensions
1730: 19.8 cm x 16.7 cm x 5.5 cm (7.8 in x 6.6 in x 2.2 in)
Power supply: 13.0 cm x 13.0 cm x 4.5 cm (5.1 in x 5.1 in x 1.8 in)
1730 with power supply attached: 19.8 cm x 16.7 cm x 9 cm
(7.8 in x 6.6 in x 3.5 in)
Weight
1730: 1.1 kg (2.5 lb)
Power supply: 400 g (0.9 lb)
External protection
Holster, Kensington lock slot
