AC Output Voltage:

Range: 50V to 5000V AC, 1V resolution
Regulation: <(1% of setting +5V) at Rated Load

Freq: 50-600 Hz, programmable in 1Hz steps

50~60Hz : 1% + 5 cnts, > 60Hz: 3%+10 cnts
Waveform: Sinusoidal

Voltage Display:

Accuracy: ±(1% of reading + 5V)
Resolution: 1Volt

AC Current Display:

Total current
Range: 0.001 to 40mA AC
Resolution: 1 or 10µA steps
Accuracy: ±(1% of reading + 5cnt)

High/Low Limit Test:

1µA to 40mA AC
Low limit can be turned OFF

Arc Detection:

Programmable 1-20mA,
Pulse Width 40µ, 20µ, 10µ or 4µsec

DC Output Voltage:

Range: 50V to 6000V DC, 1V resolution
Regulation: <(1% +5V) at Rated Load

Voltage Display:

Accuracy: ±(1% of reading + 5V)
Resolution: 1Volt

DC Current Display:

Range: 0.1µ to 12mA DC
Resolution: 0.1, 1 or 10µA steps
Accuracy: ±(1% or reading + 5cnt)

High/Low Limit Test:

0.0001mA to 12mA DC
Low limit can be turned OFF

Arc Detection:

Programmable 1-10mA
Pulse Width 40µ, 20µ, 10µ or 4µsec

Insulation Resistance:

Range: 50V - 1000V DC
Accuracy: ±5% to ±15% depending upon
voltage and resistance

Voltage Range:

100kΩ - 50GΩ

Voltage Display:

±(1% of reading + 5V)

High/Low Limit Test:

100kΩ - 50GΩ

Low limit can be turned OFF

Ground Bond:

Output Current:

Range: 1.0 to 30.0A AC, setting .01A/step; *40A
Regulation: ±(1% of setting + 0.3A)
Accuracy: ±(1% of reading + 3 counts)

Frequency:

50 or 60Hz Selectable

No Load Voltage:

6 to 15 V Programmable

Resistance:

Range: 0.1mΩ - 510mΩ , 4 digits
Accuracy: ±(1% of reading + 3 counts)
Resolution: 0.1mV

High Limit:

0.1mΩ to 510mΩ

Start Wait:

0.1 - 99.9sec

Common Features:

Open/Short Circuit Mode: Check for Open & Short against a standard

capacitance value (Cs); <100V, 600Hz

Offset Function:

0 to 100mΩ offset, user selectable
AC Programmable Offset, 0-25mA

Test Time:

Ramp: 0.3 to 999s (±20ms), (AC/DC/IR)
Dwell: 0 to 999s (±20ms), (DC only)
Start Wait: 0.1 to 99.9s (±20ms), (GB only)
Test: 0.3 to 999s (±20ms) or Continuous (ALL)
Ramp, Dwell & Start Wait can be set to OFF

Remote Control:

Inputs: Start,Stop
Characteristics: Optically Isolated, Low,
Pulse Width >1ms.
Outputs: Pass/Fail/Under Test

Characteristics: Dry Contact relay
Electrical Characteristics: 120V 100mA max.
Logic: Closed if True

Connector: Terminal Strip and 9 pin D Series

Test Setups:

100 Test Setups with 50 Steps each,
13 character Alpha-Numeric Label

Connectors:

Front and Rear 4- terminal connection

Display:

320 x 240 enhanced LCD with status indicators

Front Panel Lockout:

Key Lock with Password
Fail Lock with Password

Safety Features:

Fast Cutoff (<0.4ms) & Fast Discharge (0.2s)
Adjustable Discharge: .05-5.1kV DC

Miscellaneous:

Fail Retest; Continue on Fail
PAUSE Mode: Program pause between steps

Indication:

Pass/Fail lights, audible sound; Remote, Lock,
Offset & Error status indicators

Buzzer Level:

1,2,3 and Off

Standard Interfaces:

RS-232, Remote I/O
Data bits: 8, Stop bits: 1; Parity: None
Selectable Baud Rate: 300 - 19200

Optional Interfaces:

IEEE-488, Printer

Dimensions:

(w x h x d):17x5.25x18.5in (430x133x470mm)

Weight:

53 lbs (24kg) - Net, 60 lbs (27kg) Shipping

Environmental:

Operating: 0 to + 40° C,
Humidity: <75%
Storage: - 20 to + 70° C
Warm-up Time: 1minute

Power:

• 90 - 130V AC • 50 or 60Hz
• 200 - 250V AC • 800W max

Guardian 6000 Plus Electrical Safety Analyzer

Includes:

150798

Instruction Manual

S02

HV Lead Set, 1m

G15

Ground Continuity Lead Set

G14

Power Entry Adapter

4200-0300 AC Power Cable
520157

8A 250V Power Line Fuse

520053

4A 250V Power Line Fuse

N/A

Calibration Cert. Traceable to NIST

Optional Accessories

N/A

Calibration Data

6000-01 Scanner, 8 Channel 5HV,3GC
6000-02 Scanner, 8 Channel 3HV,5GC
6000-03 Scanner, 8 Channel HV
S04

HV Lead Set 2m

S05

Foot Switch

S08

Gun Probe

S09

HV Lead, 1M, Unterminated

S10

HV Lead, 1M, Unterminated

G13

Corded Product Adapter (115V)

G14

Power Entry Adapter

G16

International Power Strip

G24

Scanner Cable (5000 scanners)

G25

Corded Product Adapter (240V)

G38

Printer Interface (replaces IEEE)

G39

IEEE-488 Interface

G43

Rack Mount Kit

G44

Barcode Scanner

G45

40A Ground Bond Transformer

Ordering Information

Guardian 6000 Plus

*GB to 40A with optional transformer

For more detailed information on specifications, pricing and

special purchase, rent and lease options, contact us at:

www.quadtech.com

or 800-253-1230

P/N: 030145/
