AC Output Voltage: Range: 50V to 5000V AC, 1V resolution
Regulation: <(1% of setting +5V) at Rated Load
Freq: 50-600 Hz, programmable in 1Hz steps
50~60Hz : 1% + 5 cnts, > 60Hz: 3%+10 cnts
Waveform: Sinusoidal
Voltage Display: Accuracy: ±(1% of reading + 5V)
Resolution: 1Volt
AC Current Display: Total current, Range: 0.001 to 40mA AC
Resolution: 1 or 10µA steps
Accuracy: ±(1% of reading + 5cnt)
High/Low Limit Test: 1µA to 40mA AC
Low limit can be turned OFF
Arc Detection: Programmable 1-20mA,
Pulse Width 40µ, 20µ, 10µ or 4µsec
DC Output Voltage: Range: 50V to 6000V DC, 1V resolution
Regulation: <(1% of setting +5V) at Rated Load
Voltage Display: Accuracy: ±(1% of reading + 5V)
Resolution: 1Volt
DC Current Display: Range: 0.1µ to 12mA DC
Resolution: 0.1, 1 or 10µA steps
Accuracy: ±(1% or reading + 5cnt)
High/Low Limit Test: 0.0001mA to 12mA DC
Low limit can be turned OFF
Arc Detection: Programmable 1-10mA
Pulse Width 40µ, 20µ, 10µ or 4µsec
Insulation Resistance: Range: 100kV - 50GV
Accuracy: ±5% to ±15% depending upon
voltage and resistance
Voltage Range: 50V to 1000V DC
Voltage Accuracy: ±(1% of setting + 5V)
High/Low Limit Test: 100kΩ - 50GΩ
Low limit can be turned OFF
Ground Bond:
Output Current: Range: 1.0 to 30.0A AC, setting 0.1A/step; *40A
Accuracy: ±(1% of setting + 0.3A)
Frequency: 50 or 60Hz Selectable
No Load Voltage: 6 to 15 V Programmable
Resistance: Range: 0.1mΩ-510.0mV, 4 digits; Resol: 1mV
Accuracy: ±(1% of reading + 3 counts)
High Limit: 0.1mΩ to 510mΩ
Start Wait: 0.1 - 99.9sec, OFF
Leakage Current:
Input Voltage: Range: 0V to 300V
Line Voltage Meter: 0 - 300V AC, ±(1% of reading + 6cnts)
Line Current Meter: 0 - 20A, ±(1.5% of reading + 0.1A)
Power: 0 - 4400VA
High/Low Limits: Programmable for Voltage, Current, Power
Current Display: Range Res. Accuracy
0.0001-0.59mA 0.0002mA ±(2% + 5cnts)
0.6 - 9.999mA 0.003mA ±(2% + 5cnts)
Current Trip Limits: 0.1µA to 9.999mA, 1µA Resolution (Range Dep.)
0.1µA to 6.000mA for UL544NP
Measuring Circuit: 5 Human Body Models IAW UL544 NP,
UL544P, UL1563, UL2601-1,IEC60601-1, IEC
950, UL1950, UL3101 Standards
Measurement Modes: Normal, Reverse, Single Fault with Ground
ON/OFF, Earth Line Leakage, Patient Line
Leakage and Patient Auxiliary Leakage.
Max. DUT Current: 20A
Common Features:
Open/Short Circuit Mode: Check for Open & Short against a standard
capacitance value (Cs); <100V, 600Hz
Offset Function: 0 to 100mΩ offset, user selectable
Test Time: Ramp: 0.3 to 999s (±20ms), AC/DC/IR
Dwell: 0 to 999s (±20ms), DC only
Start Wait: 0.1 to 99.9s (±20ms), GB only
Test: 0.3 to 999s (±20ms) & Continuous (ALL)
Remote Control: Inputs: Start,Stop
Characteristics: Optically Isolated, Low,
Pulse Width >1ms.
Outputs: Pass/Fail/Under Test
Characteristics: Dry Contact relay
Electrical Characteristics: 120V 100mA max.
Logic: Closed if True
Connector: Terminal Strip and 9 pin D Series
Test Setups: 100 Test Setups with 50 Steps each,
13 character Alpha-Numeric Label
Connectors: Front and Rear 4- terminal connection
Display: 320 x 240 enhanced LCD with status indicators
Front Panel Lockout: Key Lock w/ Password; Fail Lock w/ Password
Safety Features: Fast Cutoff (<0.4ms) & Fast Discharge (0.2s)
Adjustable Discharge: .05-5.1kV DC
Miscellaneous: Fail Retest; Continue on Fail
PAUSE Mode: Program pause between steps
Indication: Pass/Fail lights, audible sound; Remote, Lock,
Offset & Error status indicators
Interfaces: Std RS-232, Remote I/O Opt IEEE-488, Printer
Dimensions: (w x h x d):17x5.25x18.5in (430x133x470mm)
Weight: 53 lbs (24kg) - Net, 60 lbs (27kg) Shipping
Environmental: Operating: 0 to + 40° C; Humidity: <75%
Storage: - 20 to + 70° C
Power: • 90 - 130V AC • 50 or 60Hz
• 200 - 250V AC • 800W max
Guardian 6100 Plus Safety Analyzer
Includes:
150799 Instruction Manual
S02 HV Lead Set, 1m
G15 Ground Continuity Lead Set
G30 Corded Product Adapter
G33 Power Entry Adapter
4200-0300 AC Power Cable
520157
8A 250V Power Line Fuse
520053 4A 250V Power Line Fuse
520124 20A 250V Power Line Fuse: Scanner
N/A Calibration Cert. Traceable to NIST
Optional Accessories
N/A Calibration Data
5000-01 External Scanner, 8 Channel: 8HV
5000-02 External Scanner, 8 Channel: 8HV, 4GB
5000-03 External Scanner, 8 Channel: 8HV
5000-04 External Scanner, 8 Channel: 8HV, 3GB
S04
HV Lead Set 2m
S05 Foot Switch
S08 Gun Probe
S09 HV Lead, 1m, Unterminated
S10 HV Lead, 1m, Unterminated
G13 Corded Product Adapter (115V)
G14 Power Entry Adapter
G16 International Power Strip
G24 Scanner Cable (5000 scanners)
G25 Corded Product Adapter (240V)
G31 Isolation Transformer, 500VA
G32 Isolation Transformer, 1000VA
G38 Printer Interface (replaces IEEE)
G39 IEEE-488 Interface
G43 Rack Mount Kit
G44 Barcode Scanner
G45 40A Ground Bond Transformer
630157 RS232, 9-pin (M-F), 10’ length
Ordering Information
Guardian 6100 Plus
P
ro
d
u
c
t
S
p
e
c
if
ic
a
ti
o
n
s
*GB to 40A with optional transformer
