60kVA Power Rating
General
705-60
720-60
760-60
7100-60
Input Voltage
480V, single phase, 60Hz
380V, single phase, 50Hz
Max Output Voltage
5kV AC
20kV AC
60kV AC
100kV AC
Output Current
12000mA
3000mA
1000mA
600mA
Output Connection
Shielded Output Cable
Epoxy Output Bushing
Metering
Digital, 1% of FS, range 10-100% of system output
Duty Cycle
60kVA 1 hr. ON, 1 hr. OFF/ Continuous @ 50kVA
Control / Regulator
Dimensions
30”W x 73”H x 42”D
(762 x 1855 x 1067mm)
25”W x 73”H x 30”D
(635 x 1855 x 672mm)
Control / Regulator
Weights
Net 1500lbs (680kg)
900lbs (408kg)
High Voltage
Dimensions
In Control / Regulator
Section
29”Wx37”Hx40”D
737x940x1016mm
34”Wx42”Hx49”D
864x1067x1245mm
34”Wx48”Hx55”D
864x1220x1397mm
High Voltage
Weight
In Control / Regulator
Section
Net 1600lbs
(726 kg)
Net 2000lbs
(907 kg)
Net 2540lbs
(1155 kg)
Note: Dimensions and Weights are Approximate
Other Output Ratings Available, Consult Factory with Your Requirements
Porcelain Condenser Bushings are used on systems rated >100kV with a approximate load rating of 400pF
100kVA Power Rating
General
720-100
750-100
775-100
7100-100
Input Voltage
480V, single phase, 60Hz
380V, single phase, 50Hz
Max Output Voltage
20kV AC
50kV AC
75kV AC
100kV AC
Output Current
5000mA
2000mA
1333mA
1000mA
Output Connection
Epoxy Output Bushing
Metering
Digital, 1% of FS, range 10-100% of system output
Duty Cycle
100kVA 1 hr. ON, 1 hr. OFF/Continuous @ 75kVA
Control / Regulator
Dimensions
30”W x 73”H x 42”D
(762 x 1855 x 1067mm)
Control / Regulator
Weights
Net 1400lbs (635 kg)
High Voltage
Dimensions
30”Wx39”Hx40”D
762x991x1016mm
30”Wx39”Hx40”D
762x991x1016mm
34”Wx45”Hx58”D
864x1143x1473mm
34”Wx42”Hx53D
864x1067x1346mm
High Voltage
Weight
Net 2600lbs
(1182 kg)
Net 2800lbs
(1273 kg)
Net 2900lbs
(1315 kg)
Net 3100lbs
(1409 kg)
Note: Dimensions and Weights are Approximate
Other Output Ratings Available, Consult Factory with Your Requirements
Porcelain Condenser Bushings are used on systems rated >100kV with a approximate load of 400pF
