1kVA Power Rating
General 705-1 710-1 715-1 720-1 730-1
Input Voltage
120V, 60Hz –A version
230V, 50Hz –B version
Max Output Voltage 5kV AC 10kV AC 15kV AC 20kV AC 30kV AC
Output Current 200mA 100mA 67mA 50mA 33mA
Output Connection Shielded Cable Output Epoxy Output Bushing
Metering 4.5" analog meters, ±2% full scale accuracy
Duty Cycle 1kVA 1 hr. ON, 1 hr. OFF 6 times per day 1kVA 1 hr. ON, 1 hr. Off 6 times per day
Control Dimensions
21.25”W x 15”H x 15.625”D
(540mm x 381mm x 391mm)
Control
Weights
Net 85lbs (39kg) Net 81lbs (37kg)
High Voltage
Dimensions
In Controller
12”W x 12”H x 11”D
(305mm x 305mm x 279mm)
High Voltage
Weight
In Controller 40lbs (18kg) 45lbs (20kg)
Regulator
Dimensions
In Controller
Regulator Weight In Controller
Note: Dimensions and Weights are Approximate
2kVA Power Rating
General 705-2 710-2 715-2 730-2 750-2
Input Voltage
120V, 60Hz –A version
230V, 50Hz –B version
Max Output Voltage 5kV AC 10kV AC 15kV AC 30kV AC 50kV AC
Output Current 400mA 200mA 133mA 67mA 40mA
Output Connection Shielded Cable Output Epoxy Output Bushing
Metering 4.5" analog meters, ±2% full scale accuracy
Duty Cycle 2kVA 1 hr. ON, 1 hr. OFF 6 times per day 2kVA 1 hr. ON, 1 hr. Off 6 times per day
Control / Regulator
Dimensions 21.25”W x 15”H x 15.625”D
(540mm x 381mm x 391mm)
Control / Regulator
Weights
Net 95lbs (43kg) Net 70lbs (32kg)
High Voltage
Dimensions
In Control / Regulator Section
12”W x 12”H x 11”D
(305 x 305 x
279mm)
14”W x 14”H x 12”D
(356 x 356 x
305mm)
High Voltage
Weight
In Control / Regulator Section Net 60lbs (27kg) Net 72lbs (33kg)
Note: Dimensions and Weights are Approximate
TECHNICAL SPECIFICATIONS
