ordering Information
7700 20-channel Differential
Multiplexer Module with
up to 50MHz bandwidth,
automatic CJC, and
screw Terminals
7701 32-channel Differential
Multiplexer Module with a
25- and 50-Pin female
D-sub Connector. supplied
with Male IDC ribbon
Cable Connectors
7702 40-channel Differential
Multiplexer Module w/
screw Terminals
7703 32-channel, High speed,
Differential Multiplexer
Module with 2 50-Pin female
D-sub Connectors. Includes
2 Mating Connectors
7705 40-channel, single-pole Control
Module with 2 50-Pin female
D-sub Connectors. Includes
2 Mating Connectors
7706 all-in-one I/o Module:
20-channel Differential
Multiplexer w/automatic CJC,
16 Digital outputs, 2 analog
outputs, a Counter/Totalizer,
and screw Terminals
7707 32-channel Digital I/o
w/10-channel Differential
Multiplexer Module with a 25-Pin
female and 50-Pin Male D-sub
Connectors. supplied with Mating
IDC ribbon Cable Connectors
7708 40-channel Differential
Multiplexer Module w/automatic
CJC and screw Terminals
7709 6×8 Matrix Module with
25- and 50-Pin female D-sub
Connectors. supplied with Male
IDC ribbon Cable Connectors
7710 20-channel solid-state/
long life Differential
Multiplexer w/automatic
CJC and screw Terminals
7711 2GHz 50 W rf Module with
Dual 1×4 Configuration
and sMa Connections
7712 3.5GHz 50 W rf Module with
Dual 1×4 Configuration
and sMa Connections
rugged 50-pin D-sub connectors ensure
dependability and quick setup/teardown in
production test racks.
screw terminals use oversize connectors
for easier, mistake-free wiring. Easy-to-use
removable terminals are available on some
models.
software solutions
Whether the task calls for a simple start-up package to acquire several channels of data or the tools
to create a fully custom acquisition and analysis solution, Keithley has the software needed to get the
most performance from a Model 2700, 2701, or 2750 Multimeter/Switch System . Our broad range of
software solutions makes it easy to get applications “Up & Running” quickly and economically .
Measurement ranges for the Integra series systems
Temperature—rTD
Temperature—TC
Temperature—Thermistor
Linear scale
1n 1 1m 1 1k 1M 1G
100nV 1000V
100nV 750V
10nA 3A
1 µA 3A
3Hz 500kHz
2 µs 333ms
—200 °C 630 °C
—200 °C 1820 °C
—80 °C 150 °C
10 µW 120M W
1 µW 120M W
DC Voltage
aC Voltage
DC Current
aC Current
frequency
Period
resistance (2-Wire)
resistance (4-Wire)
Logarithmic scale
Measurement ranges
—500 0 500 1000 1500 2000
Model 2750 only
2700, 2701,
2750
Multimeter/Data Acquisition/
Switch Systems
In
te
gr
