Functional Specifications
FTB-8510G
10 Gigabit Ethernet Test Module
10BASE-SW 10BASE-SR 10BASE-LW 10BASE-LR 10BASE-EW 10BASE-ER
Wavelength 850 nm 850 nm 1310 nm 1310 nm 1550 nm 1550 nm
Multimode Multimode Singlemode Singlemode Singlemode Singlemode
Tx level (802.3ae-compliant) –7.3 to –1 dBm –7.3 to –1 dBm –8.2 to +0.5 dBm –8.2 to +0.5 dBm –4.7 to +4.0 dBm –4.7 to +4.0 dBm
Rx level sensitivity –9.9 to –1.0 dBm –9.9 to –1.0 dBm –14.4 to +0.5 dBm –14.4 to +0.5 dBm –15.8 to –1.0 dBm –15.8 to –1.0 dBm
Transmission bit rate 9.95328 Gbit/s ± 4.6 ppm * 10.3125 Gbit/s ± 4.6 ppm * 9.95328 Gbit/s ± 4.6 ppm * 10.3125 Gbit/s ± 4.6 ppm * 9.95328 Gbit/s ± 4.6 ppm * 10.3125 Gbit/s ± 4.6 ppm *
Reception bit rate 9.95328 Gbit/s ± 150 ppm 10.3125 Gbit/s ± 150 ppm 9.95328 Gbit/s ± 150 ppm 10.3125 Gbit/s ± 150 ppm 9.95328 Gbit/s ± 150 ppm 10.3125 Gbit/s ± 150 ppm
Tx operational wavelength range 840 nm to 860 nm 840 nm to 860 nm 1260 nm to 1355 nm 1260 nm to 1355 nm 1530 nm to 1565 nm 1530 nm to 1565 nm
(802.3ae-compliant)
Measurement accuracy
Frequency ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm
Optical power < 2 dB < 2 dB < 2 dB < 2 dB < 2 dB < 2 dB
Maximum Rx before damage 0 dBm 0 dBm +1.5 dBm +1.5 dBm +4.0 dBm +4.0 dBm
Jitter compliance IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae
Ethernet classification IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae
Laser type VCSEL VCSEL DFB DFB EML EML
Eye safety Class 1 laser; complies Class 1 laser; complies Class 1 laser; complies Class 1 laser; complies Class 1M laser; complies Class 1M laser; complies
with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10
and IEC 60825-1 and IEC 60825-1 and IEC 60825-1 and IEC 60825-1 and IEC 60825-1 and IEC 60825-1
Connector Duplex LC Duplex LC Duplex LC Duplex LC Duplex LC Duplex LC
Transceiver type XFP XFP XFP XFP XFP XFP
(compliant with XFP MSA)
*
When clocking is in internal mode
SYNCHRONIZATION INTERFACES
DS1/E1 external input clock interface
Parameter DS1 E1
Rx level sensitivity (short haul only) For 772 kHz: For 1024 kHz:
TERM: 6 dB (cable loss only) TERM: 6 dB (cable loss only)
Reception bit rate 1.544 Mbit/s ± 50 ppm 2.048 Mbit/s ± 50 ppm
Input jitter tolerance AT&T PUB 62411, GR-499 section 7.3 G.823 section 7.2
Line coding AMI and B8ZS HDB3 and AMI
Input impedance 100 ohms ± 5%, balanced 120 ohms ± 5%, balanced
(resistive termination)
Connector type BANTAM BANTAM
OPTICAL INTERFACES
Clock out interface
Parameter Value
Tx pulse amplitude 600 mVpp ± 130 mV
Transmission frequency LAN WAN
Clock divider = 16 644.53 MHz 622.08 MHz
Clock divider = 32 322.266 MHz 311.04 MHz
Clock divider = 64 161.133 MHz 155.52 MHz
Output configuration AC coupled
Load impedance 50 ohms
Maximum cable length 3 meters
Connector type SMA
