Page 2: V height shift optimum plasma zone

1
mm
3
mm
1
mm
φ
60
µm
φ
125
µm
φ
500
µm
offset
The FSM-100 series has the revolutionary design clamp system.
- No need to change V-groove or clamp part
- Programmable for any fiber or coating size
- Reliably captures fiber for good alignment
The FSM-100 series has two electrode positioning techniques in order to provide unprecedented versatility for each specialty fiber.
Patented “Split V-groove” clamping system
Fujikura’s new specialty splicers FSM-100M and FSM-100P offer a host of innovative technology to address the rapidly expanding splicing needs for factory,
manufacturing, laboratory and R&D applications. These models are introduced as “
” splicers due to their unique capabilities to control the plasma
zone of the fusion arc. These capabilities will revolutionize the way users will splice various types of specialty fibers; LDF, low contrast PM, holey structured, etc.
Specialty Fiber Fusion Splicer
Polarization Maintaining Fiber Fusion Splicer
“Plasma Zone” fiber positioning
Electrode gap: 1 mm
Electrode gap: 3 mm
Electrode
Electrode
3
mm
1
mm
1
mm
3
mm
Electrode Gap
±
0
µm
Electrode
Electrode
−
300
µm
+
100
µm
V Height Shift
Optimum plasma Zone
a
)
b
)
c
)
Clamp
Split v-groove A
φ
500
µm
φ
60
µm
Split v-groove B
Applicable fiber:
・
Glass clamp: cladding dia.
φ
60 to 500 µm
・
Coating clamp: coating dia.
φ
100 to
φ
2000 µm
FSM-100M
FSM-100M FSM-100P
FSM-100P
